TE Connectivity 53113 Series Vertical Board PCB Socket, 210-Contact, 3 Row, 2.54 mm Pitch Solder
- RS Stock No.:
- 476-588
- Distrelec Article No.:
- 302-75-786
- Mfr. Part No.:
- 531138-7
- Brand:
- TE Connectivity
Subtotal (1 unit)*
£639.52
(exc. VAT)
£767.42
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 11 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £639.52 |
*price indicative
- RS Stock No.:
- 476-588
- Distrelec Article No.:
- 302-75-786
- Mfr. Part No.:
- 531138-7
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Socket | |
| Number of Contacts | 210 | |
| Sub Type | PCB Receptacle | |
| Number of Rows | 3 | |
| Pitch | 2.54mm | |
| Current | 3A | |
| Termination Type | Solder | |
| Housing Material | Polyphenylene Sulphide | |
| Mount Type | Board | |
| Orientation | Vertical | |
| Stacking Height | 15.24mm | |
| Connector System | Board-to-Board | |
| Series | 53113 | |
| Row Pitch | 2.54mm | |
| Minimum Operating Temperature | 65°C | |
| Maximum Operating Temperature | 125°C | |
| Contact Gender | Female | |
| Contact Material | Beryllium Copper Alloy | |
| Contact Plating | Gold | |
| Standards/Approvals | UL 94 V-0 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Socket | ||
Number of Contacts 210 | ||
Sub Type PCB Receptacle | ||
Number of Rows 3 | ||
Pitch 2.54mm | ||
Current 3A | ||
Termination Type Solder | ||
Housing Material Polyphenylene Sulphide | ||
Mount Type Board | ||
Orientation Vertical | ||
Stacking Height 15.24mm | ||
Connector System Board-to-Board | ||
Series 53113 | ||
Row Pitch 2.54mm | ||
Minimum Operating Temperature 65°C | ||
Maximum Operating Temperature 125°C | ||
Contact Gender Female | ||
Contact Material Beryllium Copper Alloy | ||
Contact Plating Gold | ||
Standards/Approvals UL 94 V-0 | ||
Non Compliant
- COO (Country of Origin):
- US
The TE Connectivity PCB Mount Receptacle is a versatile and robust connector solution designed for efficient vertical mounting in board-to-board applications. Featuring a high positioning capacity of 210 contacts, this connector ensures reliable signal transmission with its precise .1 in centreline spacing. Crafted with premium materials, including a polyphenylene sulfide housing, it supports a wide operating temperature range, making it ideal for a variety of environments. The integration of gold-plated contacts further enhances performance by providing superior conductivity and resistance to corrosion. This connector is an excellent choice for electronic designs requiring durability and dependability.
Optimised for vertical PCB mounting, facilitating space efficiency in assemblies
Designed with a 3-row matrix to cater for high-density applications
Utilises tin-lead and gold plating for effective signal integrity
Polarised mating alignment ensures a secure connection every time
Constructed to support through-hole solder termination for robust circuit boards
Offers a mounting height of 11.43 mm, fitting seamlessly into compact assemblies
Rated for a maximum current of 3 A, suitable for various electronic applications
