TE Connectivity 3-1775 Series Vertical Board PCB Header, 8 Contact(s), 2 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 481-326
- Mfr. Part No.:
- 2-292132-8
- Brand:
- TE Connectivity
Subtotal (1 pack of 200 units)*
£214.73
(exc. VAT)
£257.68
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 09 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £214.73 | £1.074 |
*price indicative
- RS Stock No.:
- 481-326
- Mfr. Part No.:
- 2-292132-8
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | 3-1775 | |
| Product Type | PCB Header | |
| Current | 4A | |
| Pitch | 2mm | |
| Housing Material | Polyamide 66 | |
| Number of Contacts | 8 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | Wire-to-Board | |
| Mount Type | Board | |
| Contact Plating | Tin Plated | |
| Contact Material | Brass | |
| Minimum Operating Temperature | -40°C | |
| Row Pitch | 2mm | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 3.2mm | |
| Standards/Approvals | RoHS | |
| Mating Pin Length | 4.2mm | |
| Voltage | 125 V | |
| Distrelec Product Id | 304-53-802 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series 3-1775 | ||
Product Type PCB Header | ||
Current 4A | ||
Pitch 2mm | ||
Housing Material Polyamide 66 | ||
Number of Contacts 8 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Connector System Wire-to-Board | ||
Mount Type Board | ||
Contact Plating Tin Plated | ||
Contact Material Brass | ||
Minimum Operating Temperature -40°C | ||
Row Pitch 2mm | ||
Termination Type Solder | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 3.2mm | ||
Standards/Approvals RoHS | ||
Mating Pin Length 4.2mm | ||
Voltage 125 V | ||
Distrelec Product Id 304-53-802 | ||
- COO (Country of Origin):
- CN
The TE Connectivity PCB Mount Header is designed for vertical wire-to-board configurations, boasting 8 positions on a compact 2 mm centerline. Engineered by te connectivity, this partially shrouded connector ensures robust electrical performance and reliability in various applications. Its through-hole soldering method facilitates secure PCB termination, making it an ideal choice for applications requiring precision and stability. The durable nylon housing not only enhances longevity but also maintains mechanical integrity under challenging conditions, allowing operation within a wide temperature range from -40°C to 105°C. With optimal specifications specified for power and signal applications, this connector aligns perfectly with industry standards, ensuring compatibility and compliance.
Partially shrouded design promotes safety and ease of use
Vertical orientation maximizes space efficiency on PCBs
Constructed from high-quality nylon for added durability
Polarized locking mechanism ensures secure mating
Compatible with leading industry standards for versatile applications
