B&R X20 Series Analogue Output Module for Use with X20 Terminal Block 12 Pin
- RS Stock No.:
- 566-509
- Mfr. Part No.:
- X20AO4622
- Brand:
- B&R
Subtotal (1 unit)*
£280.30
(exc. VAT)
£336.36
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship from another location
- Plus 7 unit(s) shipping from 09 March 2026
- Plus 5 unit(s) shipping from 30 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £280.30 |
*price indicative
- RS Stock No.:
- 566-509
- Mfr. Part No.:
- X20AO4622
- Brand:
- B&R
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | B&R | |
| Product Type | Analogue Output Module | |
| Accessory Type | Analogue Output Module | |
| Series | X20 | |
| For Use With | X20 Terminal Block 12 Pin | |
| IP Rating | IP20 | |
| Standards/Approvals | UL cULus E115267, cCSAus 244665, CE, DNV, EAC, EN 60068-2-60, FTZÚ 09 ATEX 0083X, KC, KR, LR ENV1, UKCA, ABS, ATEX, BMW GS 95011-4, BV EC33B | |
| Hazardous Area Certification | ATEX, Ex | |
| Select all | ||
|---|---|---|
Brand B&R | ||
Product Type Analogue Output Module | ||
Accessory Type Analogue Output Module | ||
Series X20 | ||
For Use With X20 Terminal Block 12 Pin | ||
IP Rating IP20 | ||
Standards/Approvals UL cULus E115267, cCSAus 244665, CE, DNV, EAC, EN 60068-2-60, FTZÚ 09 ATEX 0083X, KC, KR, LR ENV1, UKCA, ABS, ATEX, BMW GS 95011-4, BV EC33B | ||
Hazardous Area Certification ATEX, Ex | ||
- COO (Country of Origin):
- AT
The B&R Industrial Automation GmbH Analog Output Module is equipped with 4 outputs and a 13-bit digital converter resolution (including sign). It allows selection between current and voltage signals through different terminals. The module provides configurable analog outputs for current and/or voltage signals, offering versatile control options for various applications.
4 inputs
13 bit converter resolution
CE and UKCA certified
