TE Connectivity AMPMODU Series Straight Cable PCB Connector, 18 Contact(s), 2.54 mm Pitch, 1 Row(s)
- RS Stock No.:
- 504-594
- Mfr. Part No.:
- 1-104257-7
- Brand:
- TE Connectivity
Subtotal (1 bag of 70 units)*
£172.89
(exc. VAT)
£207.47
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 + | £172.89 | £2.47 |
*price indicative
- RS Stock No.:
- 504-594
- Mfr. Part No.:
- 1-104257-7
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Connector | |
| Series | AMPMODU | |
| Pitch | 2.54mm | |
| Current | 3A | |
| Number of Contacts | 18 | |
| Housing Material | Thermoplastic | |
| Number of Rows | 1 | |
| Orientation | Straight | |
| Mount Type | Cable | |
| Connector System | Wire-to-Board | |
| Termination Type | Crimp | |
| Minimum Operating Temperature | 65°C | |
| Row Pitch | 2.54mm | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | UL 94 V-0 | |
| Voltage | 267 V | |
| Distrelec Product Id | 304-48-116 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Connector | ||
Series AMPMODU | ||
Pitch 2.54mm | ||
Current 3A | ||
Number of Contacts 18 | ||
Housing Material Thermoplastic | ||
Number of Rows 1 | ||
Orientation Straight | ||
Mount Type Cable | ||
Connector System Wire-to-Board | ||
Termination Type Crimp | ||
Minimum Operating Temperature 65°C | ||
Row Pitch 2.54mm | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals UL 94 V-0 | ||
Voltage 267 V | ||
Distrelec Product Id 304-48-116 | ||
- COO (Country of Origin):
- CN
The TE Connectivity Housing receptacle for wire-to-board connections is designed to deliver reliable performance in demanding environments. This product seamlessly accommodates 18 positions with a precise 2.54 mm centreline, ensuring optimal signal integrity and connection stability. Engineered with a crimp and insulation displacement technique, it allows for effortless termination to wire and cable, while its compact design facilitates efficient space utilisation on PCBs. The sleek black thermoplastic housing not only enhances the aesthetic appeal but also provides robust durability against environmental stressors. Ideal for various applications, this receptacle is a crucial component in creating dependable electronic connections across a multitude of industries.
Accommodates 18 positions for versatile connectivity
Engineered with crimp and insulation displacement technology for easy assembly
Compact design enables optimal use of limited PCB space
Constructed from thermoplastic material for enhanced durability
Offers reliable signal integrity for demanding applications
Meets stringent UL flammability ratings for safety assurance
Mating retention design ensures secure connections during use
Compatible with various wire to board connectors for seamless integration
