TE Connectivity AMPMODU Series Vertical PCB PCB Header, 4 Contact(s), 2 mm Pitch, 2 Row(s), Unshrouded

View all PCB Headers

Subtotal (1 box of 600 units)*

£179.38

(exc. VAT)

£215.26

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 08 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es)
Per Box
Per unit*
1 +£179.38£0.299

*price indicative

RS Stock No.:
468-310
Mfr. Part No.:
2842138-2
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Series

AMPMODU

Product Type

PCB Header

Current

2A

Pitch

2mm

Number of Contacts

4

Housing Material

Polyamide Fibreglass

Number of Rows

2

Orientation

Vertical

Shrouded/Unshrouded

Unshrouded

Connector System

Board-to-Board

Mount Type

PCB

Contact Material

Brass

Contact Plating

Gold

Row Pitch

2mm

Minimum Operating Temperature

-40°C

Termination Type

Solder

Maximum Operating Temperature

125°C

Tail Pin Length

2.8mm

Mating Pin Length

4mm

Standards/Approvals

UL 94V-0, UL E28476

Voltage

125 V

Distrelec Product Id

304-64-036

COO (Country of Origin):
CN
The TE Connectivity PCB Mount Header is expertly designed for vertical board-to-board connections, featuring four positions and a 2 mm centreline. With its breakaway design and high-quality gold plating, the header delivers reliable signal performance for a variety of applications. Crafted for through-hole soldering, it is ideal for robust circuit board assemblies. The header's durable construction incorporates PA9T GF housing material, which meets high-temperature ratings, ensuring performance stability even in demanding environments. Suitable for both commercially and industrially relevant uses, this connector assembly ensures compatibility with a range of devices and OEM standards, making it a critical component for electronic engineers and device manufacturers alike.

Breakaway type allows for flexible board configurations

Vertical orientation optimises space in compact assemblies

Robust construction guarantees lasting durability

Designed to facilitate easy soldering to printed circuit boards

Nickel underplating enhances conductivity and longevity

Compact form factor ideal for space constrained applications

Reliable operating temperature range supports diverse environments

Signal application tailored for efficiency in data transmission

Compliance with European directive standards ensures quality assurance
