TE Connectivity Economy Power 2.5 Series Vertical Board PCB Header, 8 Contact(s), 2.5 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 467-500
- Mfr. Part No.:
- 2132415-8
- Brand:
- TE Connectivity
Subtotal (1 bag of 800 units)*
£204.62
(exc. VAT)
£245.54
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 + | £204.62 | £0.256 |
*price indicative
- RS Stock No.:
- 467-500
- Mfr. Part No.:
- 2132415-8
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Header | |
| Series | Economy Power 2.5 | |
| Pitch | 2.5mm | |
| Current | 4.2A | |
| Housing Material | Fibreglass Reinforced Polybutylene Terephthalate | |
| Number of Contacts | 8 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Board | |
| Connector System | Wire-to-Board | |
| Contact Plating | Tin Plated | |
| Contact Material | Brass | |
| Termination Type | Solder | |
| Row Pitch | 2.5mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 3.4mm | |
| Contact Gender | Male | |
| Mating Pin Length | 3.6mm | |
| Standards/Approvals | UL 94V-0, VDE | |
| Voltage | 250 V | |
| Distrelec Product Id | 304-50-559 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Header | ||
Series Economy Power 2.5 | ||
Pitch 2.5mm | ||
Current 4.2A | ||
Housing Material Fibreglass Reinforced Polybutylene Terephthalate | ||
Number of Contacts 8 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Board | ||
Connector System Wire-to-Board | ||
Contact Plating Tin Plated | ||
Contact Material Brass | ||
Termination Type Solder | ||
Row Pitch 2.5mm | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 3.4mm | ||
Contact Gender Male | ||
Mating Pin Length 3.6mm | ||
Standards/Approvals UL 94V-0, VDE | ||
Voltage 250 V | ||
Distrelec Product Id 304-50-559 | ||
- COO (Country of Origin):
- CN
The TE Connectivity PCB Mount Header is designed for seamless integration in vertical applications, facilitating reliable wire-to-board connections. This innovative connector features eight positions with a 2.5 mm centreline, ensuring optimal functionality for electronic assemblies. Its fully shrouded design enhances protection whilst facilitating straightforward soldering to printed circuit boards. Constructed with robust materials, this connector supports operating voltages up to 250 VAC and is engineered to withstand a temperature range from -55 to 105 °C. The unique properties of the component ensure exceptional performance across diverse applications, making it a preferred choice for designers and engineers seeking durability and reliability in power and signal distribution.
Provides a fully shrouded header for enhanced protection during operation
Installs easily thanks to its through-hole solder termination method
Ensures stable electrical contact with a fully loaded configuration
Features a natural colour housing made from high-quality PBT GF
Designed for efficient mechanical attachment with a latching mating retention type
Compatible with wave soldering processes, assuring versatility in manufacturing
Leverages inline contact layout for optimal space utilisation on PCBs
Offers a calculation of mating retention type with polarization for precision alignment
