FLIR VT8 Clamp Meter, 100A dc, Max Current 100A ac CAT III 600V With RS Calibration

View all Clamp Meters
Currently unavailable
Sorry, we don't know when this will be back in stock.
RS Stock No.:
181-2434
Mfr. Part No.:
VT8-600
Brand:
FLIR
Find similar products by selecting one or more attributes.
Select all

Brand

FLIR

Absolute Maximum AC Current Measurement

100A ac

Absolute Maximum DC Current Measurement

100A dc

Absolute Maximum AC Voltage Measurement

600V ac

Absolute Maximum DC Voltage Measurement

600V dc

Absolute Maximum Resistance Measurement

60MΩ

Model Number

VT8

Calibrated

RSCAL

AC Current Measurement Resolution

100mA

DC Current Measurement Resolution

100mA

Best DC Current Accuracy

±2.5 %

Clamp Meter Type

AC-DC Open Jaw Clamp Meter

Best AC Current Accuracy

±2.5 %

Best AC Voltage Accuracy

±1.5 %

True RMS

Yes

Functions Measured

AC Current, AC Voltage, Auto-Ranging, Capacitance, Continuity, Data Hold, DC Current, DC Voltage, DCA Zero, Non-Contact Voltage Detector (NCV), Relative Mode, Resistance, True RMS

Best DC Voltage Accuracy

±1.5 %

Jaw Capacity Busbars

15.5mm

Weight

163.7g

Width

35mm

AC Voltage Measurement Resolution

100mV

Length

210mm

Height

53mm

Non-Contact Voltage Detector

Yes

Safety Category Level

CAT III, CAT IV

Power Source

Battery

Minimum Operating Temperature

-10°C

Battery Type

AA

Dimensions

210 x 35 x 53mm

Safety Category

CAT III 600 V, CAT IV 300V

Best Resistance Measurement Accuracy

±1.5 %

Display Type

LCD

Maximum Operating Temperature

+50°C

DC Voltage Measurement Resolution

100mV

Safety Category Voltage

300 V, 600V

COO (Country of Origin):
CN

FLIR VT8-600 Voltage, Current and Continuity Tester


From FLIR, the true RMS VT8-600 clamp meter with a 100A /600V measuring range. The superior instrument is perfect for electricians, technicians and engineers for verification and troubleshooting. Typically, within the commercial and light industrial sectors.

Ergonomically designed, the clamp meter is comfortably operated with one hand. With a 15.5mm fixed jaw clamp, amperage measurements are easily taken in tight spaces, the optimised jaw design also caters for larger diameter cables. A handy built-in test lead holder on the back of the instrument safely stores leads when not in use.

With built-in bright LED worklights, the FLIR VT8-600 clamp meter provides extra illumination for environments with very little or no light. Readings are clearly visible on the large multifunction backlit LCD display, ideal for dark cabinets and panels.

Compact and lightweight the FLIR VT8-600 clamp meter is extremely easy to operate. Robust, sturdy and built to last this professional all-in-one tool is the essential instrument for every engineer.

Features and Benefits


  • AC/DC voltage range 0 to 600V

  • AC/DC current range 0 to 100 A

  • True RMS

  • Resistance 60.00MΩ, ± (1.5%)

  • Capacitance 600μF, ±4%; 6000μF, ±10%

  • Continuity check threshold: 10Ω to 100Ω

  • Non-Contact Voltage Detector (NVC)

  • Additional measurement functions: DCA zero, relative mode (AC/DC voltage, AC current, and capacitance), data hold

  • Bright white LED work lights

  • 6000-count backlit LCD display

  • Over range indication displayed ’OL’ or ’-OL’

  • Auto power off after 15 minutes

  • Low battery indication

  • Drop tested to 2m

Applications


Voltage and continuity testers are electrical test tools widely used by service engineers, technicians and electricians to safely measure electrical equipment is working correctly. The instruments can help to diagnose and troubleshoot. Some of the most common applications are

  • Electrical energy

  • Facility maintenance and management

  • Home inspections

  • Utilities

Optional Extras


  • 123-6703 is for the FLIR TA15 Soft Case

  • 187-4892 is for the FLIR TA70 CAT IV Insulated Alligator Probes

  • 193-2382 is for the FLIR TA83 Replacement Test Leads

FLIR Clamp metre, AC-DC, True RMS - VT8-600


This FLIR VT8 AC-DC clamp metre is a versatile tool designed for professionals in the automation, electronics, electrical, and mechanical industries. With its open-jaw design, the FLIR VT8 can measure large-diametre cables in tight spaces, making it ideal for troubleshooting electrical installations. The True RMS technology ensures accurate measurements, while the non-contact voltage detector adds an extra layer of safety to your work.

Features & Benefits


• Measure AC/DC voltage and current, continuity, resistance, and capacitance with high accuracy
• Bright LED work-light and backlit display for easy operation in dimly lit areas
• Built-in non-contact voltage (NCV) detector to detect live AC voltages
• True RMS measurements for improved accuracy
• CAT III CAT IV safety ratings for enhanced safety during measurements

Applications


• Ideal for electricians and service technicians in commercial and light industrial facilities
• Perfect for troubleshooting electrical systems and verifying installations
• Suitable for professionals working in automation, electronics, electrical, and mechanical industries
• Can be used to measure a wide range of electrical parametres with precision

Can it measure both AC and DC voltage and current accurately?


Yes, the FLIR VT8 AC-DC clamp metre can measure both AC and DC voltage and current with high accuracy.

Will it help me detect live AC voltages without contact?


Yes, the FLIR VT8 is equipped with a non-contact voltage (NCV) detector to help you detect live AC voltages safely.

Is it suitable for professionals working in the automation industry?


Yes, the clamp metre is designed to meet the needs of professionals in the automation industry.
