FLIR VT8 Clamp Meter, 100A dc, Max Current 100A ac CAT III 600V

RS Stock No.:: 181-2426
Distrelec Article No.:: 301-25-653
Mfr. Part No.:: VT8-600
Brand:: FLIR

FLIR VT8 Clamp Meter, 100A dc, Max Current 100A ac CAT III 600V

Unavailable

RS will no longer stock this product.

RS Stock No.:: 181-2426
Distrelec Article No.:: 301-25-653
Mfr. Part No.:: VT8-600
Brand:: FLIR

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	FLIR
	Absolute Maximum AC Current Measurement	100A ac
	Absolute Maximum DC Current Measurement	100A dc
	Absolute Maximum AC Voltage Measurement	600V ac
	Absolute Maximum DC Voltage Measurement	600V dc
	Absolute Maximum Resistance Measurement	60MΩ
	Model Number	VT8
	AC Current Measurement Resolution	100mA
	DC Current Measurement Resolution	100mA
	Best DC Current Accuracy	±2.5 %
	Clamp Meter Type	AC-DC Open Jaw Clamp Meter
	Best AC Current Accuracy	±2.5 %
	Best AC Voltage Accuracy	±1 %
	Best DC Voltage Accuracy	±1 %
	Jaw Capacity Busbars	15.5mm
	True RMS	Yes
	Functions Measured	AC Current, AC Voltage, Auto-Ranging, Capacitance, Continuity, Data Hold, DC Current, DC Voltage, DCA Zero, Non-Contact Voltage Detector (NCV), Relative Mode, Resistance, True RMS
	Width	35mm
	AC Voltage Measurement Range	1000 V
	AC Voltage Measurement Resolution	100mV
	DC Current Measurement Range	200 A
	Dimensions	210 x 35 x 53mm
	Length	210mm
	AC Current Measurement Range	200 A
	Power Source	Battery
	Non-Contact Voltage Detector	Yes
	Safety Category Level	CAT III, CAT IV
	Weight	163.7g
	Minimum Operating Temperature	-10°C
	DC Voltage Measurement Resolution	100mV
	Height	53mm
	Safety Category	CAT III 600 V, CAT IV 300V
	Best Resistance Measurement Accuracy	±1.5 %
	Battery Type	AA
	Safety Category Voltage	300 V, 600V
	Display Type	LCD
	Maximum Operating Temperature	+50°C

	Select all
	Brand FLIR
	Absolute Maximum AC Current Measurement 100A ac
	Absolute Maximum DC Current Measurement 100A dc
	Absolute Maximum AC Voltage Measurement 600V ac
	Absolute Maximum DC Voltage Measurement 600V dc
	Absolute Maximum Resistance Measurement 60MΩ
	Model Number VT8
	AC Current Measurement Resolution 100mA
	DC Current Measurement Resolution 100mA
	Best DC Current Accuracy ±2.5 %
	Clamp Meter Type AC-DC Open Jaw Clamp Meter
	Best AC Current Accuracy ±2.5 %
	Best AC Voltage Accuracy ±1 %
	Best DC Voltage Accuracy ±1 %
	Jaw Capacity Busbars 15.5mm
	True RMS Yes
	Functions Measured AC Current, AC Voltage, Auto-Ranging, Capacitance, Continuity, Data Hold, DC Current, DC Voltage, DCA Zero, Non-Contact Voltage Detector (NCV), Relative Mode, Resistance, True RMS
	Width 35mm
	AC Voltage Measurement Range 1000 V
	AC Voltage Measurement Resolution 100mV
	DC Current Measurement Range 200 A
	Dimensions 210 x 35 x 53mm
	Length 210mm
	AC Current Measurement Range 200 A
	Power Source Battery
	Non-Contact Voltage Detector Yes
	Safety Category Level CAT III, CAT IV
	Weight 163.7g
	Minimum Operating Temperature -10°C
	DC Voltage Measurement Resolution 100mV
	Height 53mm
	Safety Category CAT III 600 V, CAT IV 300V
	Best Resistance Measurement Accuracy ±1.5 %
	Battery Type AA
	Safety Category Voltage 300 V, 600V
	Display Type LCD
	Maximum Operating Temperature +50°C

FLIR VT8-600 Voltage, Current and Continuity Tester

From FLIR, the true RMS VT8-600 clamp meter with a 100A /600V measuring range. The superior instrument is perfect for electricians, technicians and engineers for verification and troubleshooting. Typically, within the commercial and light industrial sectors.

Ergonomically designed, the clamp meter is comfortably operated with one hand. With a 15.5mm fixed jaw clamp, amperage measurements are easily taken in tight spaces, the optimised jaw design also caters for larger diameter cables. A handy built-in test lead holder on the back of the instrument safely stores leads when not in use.

With built-in bright LED worklights, the FLIR VT8-600 clamp meter provides extra illumination for environments with very little or no light. Readings are clearly visible on the large multifunction backlit LCD display, ideal for dark cabinets and panels.

Compact and lightweight the FLIR VT8-600 clamp meter is extremely easy to operate. Robust, sturdy and built to last this professional all-in-one tool is the essential instrument for every engineer.

Features and Benefits

AC/DC voltage range 0 to 600V

AC/DC current range 0 to 100 A

True RMS

Resistance 60.00MΩ, ± (1.5%)

Capacitance 600μF, ±4%; 6000μF, ±10%

Continuity check threshold: 10Ω to 100Ω

Non-Contact Voltage Detector (NVC)

Additional measurement functions: DCA zero, relative mode (AC/DC voltage, AC current, and capacitance), data hold

Bright white LED work lights

6000-count backlit LCD display

Over range indication displayed ’OL’ or ’-OL’

Auto power off after 15 minutes

Low battery indication

Drop tested to 2m

Applications

Voltage and continuity testers are electrical test tools widely used by service engineers, technicians and electricians to safely measure electrical equipment is working correctly. The instruments can help to diagnose and troubleshoot. Some of the most common applications are

Electrical energy

Facility maintenance and management

Home inspections

Utilities

Optional Extras

123-6703 is for the FLIR TA15 Soft Case

187-4892 is for the FLIR TA70 CAT IV Insulated Alligator Probes

193-2382 is for the FLIR TA83 Replacement Test Leads

FLIR Clamp metre, AC-DC, True RMS - VT8-600

This FLIR VT8 AC-DC clamp metre is a versatile tool designed for professionals in the automation, electronics, electrical, and mechanical industries. With its open-jaw design, the FLIR VT8 can measure large-diametre cables in tight spaces, making it ideal for troubleshooting electrical installations. The True RMS technology ensures accurate measurements, while the non-contact voltage detector adds an extra layer of safety to your work.

Features & Benefits

• Measure AC/DC voltage and current, continuity, resistance, and capacitance with high accuracy
• Bright LED work-light and backlit display for easy operation in dimly lit areas
• Built-in non-contact voltage (NCV) detector to detect live AC voltages
• True RMS measurements for improved accuracy
• CAT III CAT IV safety ratings for enhanced safety during measurements

Applications

• Ideal for electricians and service technicians in commercial and light industrial facilities
• Perfect for troubleshooting electrical systems and verifying installations
• Suitable for professionals working in automation, electronics, electrical, and mechanical industries
• Can be used to measure a wide range of electrical parametres with precision

Can it measure both AC and DC voltage and current accurately?

Yes, the FLIR VT8 AC-DC clamp metre can measure both AC and DC voltage and current with high accuracy.

Will it help me detect live AC voltages without contact?

Yes, the FLIR VT8 is equipped with a non-contact voltage (NCV) detector to help you detect live AC voltages safely.

Is it suitable for professionals working in the automation industry?

Yes, the clamp metre is designed to meet the needs of professionals in the automation industry.
