TE Connectivity Surface Power Relay, 110V dc Coil, 30A Switching Current, 1 NO
- RS Stock No.:
- 477-678
- Distrelec Article No.:
- 304-60-019
- Mfr. Part No.:
- 1558666-9
- Brand:
- TE Connectivity
Subtotal (1 tube of 50 units)*
£158.98
(exc. VAT)
£190.78
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 01 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £158.98 | £3.18 |
*price indicative
- RS Stock No.:
- 477-678
- Distrelec Article No.:
- 304-60-019
- Mfr. Part No.:
- 1558666-9
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Coil Voltage | 110V dc | |
| Product Type | Power Relay | |
| Contact Configuration | 1 NO | |
| Mount Type | Surface | |
| Series | Potter & Brumfield T9G | |
| Terminal Type | Solder | |
| Switching Current | 30A | |
| Switching AC Voltage | 480V ac | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 105°C | |
| Coil Resistance | 13.4kΩ | |
| Coil Power | 0.9W | |
| Length | 29mm | |
| Width | 21.5mm | |
| Standards/Approvals | China RoHS 2 Directive MIIT Order No 32, 2016, EU ELV Directive 2000/53/EC, EU REACH Regulation (EC) No. 1907/2006, EU RoHS Directive 2011/65/EU, UL, VDE | |
| Height | 15.7mm | |
| Contact Material | Silver Tin Oxide | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Coil Voltage 110V dc | ||
Product Type Power Relay | ||
Contact Configuration 1 NO | ||
Mount Type Surface | ||
Series Potter & Brumfield T9G | ||
Terminal Type Solder | ||
Switching Current 30A | ||
Switching AC Voltage 480V ac | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 105°C | ||
Coil Resistance 13.4kΩ | ||
Coil Power 0.9W | ||
Length 29mm | ||
Width 21.5mm | ||
Standards/Approvals China RoHS 2 Directive MIIT Order No 32, 2016, EU ELV Directive 2000/53/EC, EU REACH Regulation (EC) No. 1907/2006, EU RoHS Directive 2011/65/EU, UL, VDE | ||
Height 15.7mm | ||
Contact Material Silver Tin Oxide | ||
The TE Connectivity general purpose power relay is engineered for reliability in various applications. Designed with a monostable configuration, this relay offers a single pole and normally open contact arrangement, making it ideal for switching DC loads. With a robust 30 A contact rating and a coil voltage of 110 VDC, it ensures effective performance under demanding conditions. This relay's compact design allows for easy integration into PCB layouts, while the flux-resistant enclosure ensures durability against environmental factors. Whether for industrial use or electronic devices, this relay stands out as a versatile component across multiple sectors.
Monostable coil magnetic system enhances operational efficiency
Environmental protection category RTIII provides superior reliability
Standardised dimensions facilitate seamless mounting and integration
Solder pins ensure secure and stable connections
AgSnO contact material promotes long-lasting performance
Wave solder capable for efficient manufacturing processes
Operating temperature range supports diverse application settings
