TE Connectivity Buchanan Series Pluggable Terminal Block, 3-Contact, 3.5 mm Pitch, 1 Row, 1986716-3
- RS Stock No.:
- 478-457
- Distrelec Article No.:
- 304-59-241
- Mfr. Part No.:
- 1986716-3
- Brand:
- TE Connectivity
Subtotal (1 box of 40 units)*
£137.65
(exc. VAT)
£165.18
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 27 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £137.65 | £3.441 |
*price indicative
- RS Stock No.:
- 478-457
- Distrelec Article No.:
- 304-59-241
- Mfr. Part No.:
- 1986716-3
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | Pluggable Terminal Block | |
| Number of Contacts | 3 | |
| Pitch | 3.5mm | |
| Current | 2A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.5mm² | |
| Housing Material | Polyamide 66 | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 20 AWG | |
| Maximum Wire Size AWG | 16 AWG | |
| Orientation | Vertical | |
| Wire Connection Method | Push-in | |
| Colour | Green | |
| Voltage | 150 V | |
| Standards/Approvals | UL | |
| Depth | 12.5mm | |
| Series | Buchanan | |
| Width | 17 mm | |
| Length | 12.08mm | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type Pluggable Terminal Block | ||
Number of Contacts 3 | ||
Pitch 3.5mm | ||
Current 2A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.5mm² | ||
Housing Material Polyamide 66 | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 20 AWG | ||
Maximum Wire Size AWG 16 AWG | ||
Orientation Vertical | ||
Wire Connection Method Push-in | ||
Colour Green | ||
Voltage 150 V | ||
Standards/Approvals UL | ||
Depth 12.5mm | ||
Series Buchanan | ||
Width 17 mm | ||
Length 12.08mm | ||
- COO (Country of Origin):
- IT
The TE Connectivity 3 Position PCB Terminal Block is designed to deliver reliable connections for wire-to-board applications. With its 3.5 mm centreline, this compact solution is engineered to accommodate a variety of wire sizes, ensuring flexibility in your electrical setups. The terminal block features a vertical orientation and is crafted from durable materials to withstand operating temperatures ranging from -40 to 110 °C. Its 45° wire entry angle simplifies installation in tight spaces while providing optimal performance for signal applications. This product is ideal for projects that demand both robustness and precision, making it a perfect addition to any electronics assembly.
Single row design optimises space on circuit boards
Spring terminal termination method enhances connection security
Nickel underplating ensures excellent conductivity
Low halogen content contributes to eco-friendliness
Side stackable configuration allows for customisable setups
Wave solder capability accommodates high-efficiency manufacturing processes
Compliant with EU regulations to minimise environmental impact
Packaging quantity of 200 promotes bulk purchases and project readiness
