RS PRO Straight Through Hole PCB Header, 5 Contact(s), 5 mm Pitch, 1 Row, Shrouded

RS Stock No.:: 631-133
Brand:: RS PRO

RS PRO Straight Through Hole PCB Header, 5 Contact(s), 5 mm Pitch, 1 Row, Shrouded

Bulk discount available

View bulk pricing options

Subtotal (1 bag of 5 units)*

£10.18

(exc. VAT)

£12.22

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

97 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Bag(s)	Per Bag	Per unit*
1 - 4	£10.18	£2.036
5 - 9	£9.37	£1.874
10 +	£8.44	£1.688

*price indicative

RS Stock No.:: 631-133
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Product Type	PCB Header
	Series	RS PRO
	Current	16A
	Pitch	5mm
	Number of Contacts	5
	Housing Material	PBT
	Number of Rows	1
	Orientation	Straight
	Shrouded/Unshrouded	Shrouded
	Connector System	Board-to-Board, Board-to-Wire
	Mount Type	Through Hole
	Contact Plating	Tin
	Contact Material	Brass
	Termination Type	Screw
	Minimum Operating Temperature	-40°C
	Tail Pin Length	4.2mm
	Maximum Operating Temperature	105°C
	Contact Gender	Male
	Standards/Approvals	CE, REACH, RoHS, UL, VDE
	Voltage	300V

	Select all
	Brand RS PRO
	Product Type PCB Header
	Series RS PRO
	Current 16A
	Pitch 5mm
	Number of Contacts 5
	Housing Material PBT
	Number of Rows 1
	Orientation Straight
	Shrouded/Unshrouded Shrouded
	Connector System Board-to-Board, Board-to-Wire
	Mount Type Through Hole
	Contact Plating Tin
	Contact Material Brass
	Termination Type Screw
	Minimum Operating Temperature -40°C
	Tail Pin Length 4.2mm
	Maximum Operating Temperature 105°C
	Contact Gender Male
	Standards/Approvals CE, REACH, RoHS, UL, VDE
	Voltage 300V

COO (Country of Origin):: CN

RS PRO 5 mm Pitch PCB Header, 16 A Current

This RS PRO PCB Header is designed for reliable electrical connections in various industrial applications. With a robust shrouded design, it ensures secure connections between boards or wires, making it Ideal for high-current and high-voltage environments.

Features and Benefits

Board-to-Board and Board-to-Wire Connectivity: Offers versatile connection options for different configurations.
Male Contact Gender: Ensures compatibility with a wide range of female connectors.
Brass Contacts with Tin Plating: Provides excellent conductivity and corrosion resistance.
16 A Current Rating: Suitable for high-power applications.
PBT Housing Material: Offers durability and resistance to high temperatures and chemicals.
Operating Temperature Range -40 °C to 105 °C: Ensures reliable performance in extreme conditions.
Through Hole Mount Type: Provides secure and stable mounting on PCBs.
Shrouded Design: Protects contacts from damage and ensures proper alignment.

Applications

Industrial automation
Power distribution
Control panels
Consumer electronics
