RS PRO XY103 Series 45° Through Hole PCB Header, 5 Contact(s), 5 mm Pitch, 1 Row, Shrouded

RS Stock No.:: 631-126
Brand:: RS PRO

RS PRO XY103 Series 45° Through Hole PCB Header, 5 Contact(s), 5 mm Pitch, 1 Row, Shrouded

Bulk discount available

View bulk pricing options

Subtotal (1 bag of 5 units)*

£23.92

(exc. VAT)

£28.70

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

Plus 400 unit(s) shipping from 27 July 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Bag(s)	Per Bag	Per unit*
1 - 4	£23.92	£4.784
5 +	£22.00	£4.40

*price indicative

RS Stock No.:: 631-126
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Product Type	PCB Header
	Series	XY103
	Pitch	5mm
	Current	10A
	Number of Contacts	5
	Housing Material	PA66
	Number of Rows	1
	Orientation	45°
	Shrouded/Unshrouded	Shrouded
	Mount Type	Through Hole
	Connector System	Board-to-Board, Board-to-Wire
	Contact Material	Brass
	Contact Plating	Tin
	Minimum Operating Temperature	-40°C
	Termination Type	Screw
	Maximum Operating Temperature	105°C
	Contact Gender	Male
	Tail Pin Length	3.8mm
	Standards/Approvals	ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
	Voltage	250, 300V

	Select all
	Brand RS PRO
	Product Type PCB Header
	Series XY103
	Pitch 5mm
	Current 10A
	Number of Contacts 5
	Housing Material PA66
	Number of Rows 1
	Orientation 45°
	Shrouded/Unshrouded Shrouded
	Mount Type Through Hole
	Connector System Board-to-Board, Board-to-Wire
	Contact Material Brass
	Contact Plating Tin
	Minimum Operating Temperature -40°C
	Termination Type Screw
	Maximum Operating Temperature 105°C
	Contact Gender Male
	Tail Pin Length 3.8mm
	Standards/Approvals ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
	Voltage 250, 300V

COO (Country of Origin):: CN

RS PRO 5 mm Pitch PCB Header, Male, Through Hole

This RS PRO PCB Header is designed for reliable electrical connections in various electronic applications. With a robust construction and a shrouded design, it ensures secure and stable connections, making it Ideal for both board-to-board and board-to-wire systems.

Features and Benefits

5 mm Pitch: Provides optimal spacing for efficient circuit design and integration.
5 Contacts: Suitable for multiple connection points, enhancing versatility in applications.
Male Contact Gender: Ensures compatibility with female connectors for seamless integration.
Brass Contact Material: Offers excellent conductivity and durability.
Tin Contact Plating: Provides corrosion resistance, extending the lifespan of the connector.
Through Hole Mount Type: Facilitates easy installation and secure attachment to PCBs.
45° Orientation: Allows for flexible design configurations and space-saving installations.
Shrouded Design: Protects contacts from damage and ensures proper alignment during mating.
Screw Termination Type: Ensures a secure and reliable connection, reducing the risk of disconnection.

Applications

Industrial electronics
Consumer electronics
Telecommunications
Automotive systems

Additional Information

Complies with ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE standards
Operating temperature range from -40 °C to 105 °C
Voltage rating of 250 V VDE and 300 V UL
Housing MADE from Durable PA66 material
Tail pin length of 3.8 mm for secure PCB insertion

Why RS PRO?

RS PRO is the own brand of RS, offering professional quality products and solutions across all industries and technologies. Our product range is rigorously tested, inspected, and audited against demanding international standards to provide you with industrial-grade quality, at the right price. Making RS PRO your smart choice.
