TE Connectivity RAST 5 IDC Connectors Series Vertical Board PCB Header, 5 Contact(s), 5 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 482-368
- Mfr. Part No.:
- 521383-5
- Brand:
- TE Connectivity
Subtotal (1 pack of 192 units)*
£202.09
(exc. VAT)
£242.51
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 09 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £202.09 | £1.053 |
*price indicative
- RS Stock No.:
- 482-368
- Mfr. Part No.:
- 521383-5
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | RAST 5 IDC Connectors | |
| Product Type | PCB Header | |
| Current | 16A | |
| Pitch | 5mm | |
| Number of Contacts | 5 | |
| Housing Material | Polyamide 66 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | Wire-to-Board | |
| Mount Type | Board | |
| Contact Plating | Tin Plated | |
| Contact Material | Brass | |
| Row Pitch | 5mm | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 3.5mm | |
| Standards/Approvals | UL, UL 94V-0, UL E28476 | |
| Voltage | 250 V | |
| Distrelec Product Id | 304-54-246 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series RAST 5 IDC Connectors | ||
Product Type PCB Header | ||
Current 16A | ||
Pitch 5mm | ||
Number of Contacts 5 | ||
Housing Material Polyamide 66 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Connector System Wire-to-Board | ||
Mount Type Board | ||
Contact Plating Tin Plated | ||
Contact Material Brass | ||
Row Pitch 5mm | ||
Termination Type Solder | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 3.5mm | ||
Standards/Approvals UL, UL 94V-0, UL E28476 | ||
Voltage 250 V | ||
Distrelec Product Id 304-54-246 | ||
- COO (Country of Origin):
- CN
The TE Connectivity PCB Mount Header is designed for vertical wire-to-board applications, providing a reliable connection in a compact form factor. Featuring five positions, it boasts a fully shrouded design that enhances safety and ensures ease of use. Constructed from high-quality materials, including nylon 6/6, this connector is engineered to withstand operating temperatures from -40°C to 105°C, making it suitable for a variety of industrial environments. The connector features a 5 mm centreline pitch, ensuring compatibility with standard PCB layouts, while its sleek black finish presents a professional aesthetic. With its exceptional durability and performance characteristics, this connector is an ideal choice for power applications, ensuring long-lasting reliability in demanding situations.
Matte finish on plating reduces glare, improving visibility
Wave solder capable to 265°C enhances manufacturing flexibility
Compliant with critical industry standards for quality assurance
Easy to install with through-hole solder termination method
Compact dimensions cater to space-constrained applications
Designed for versatility in a wide range of applications
