RS PRO XY103 Series 45° Through Hole PCB Header, 4 Contact(s), 5 mm Pitch, 1 Row, Shrouded

RS Stock No.:: 631-127
Brand:: RS PRO

RS PRO XY103 Series 45° Through Hole PCB Header, 4 Contact(s), 5 mm Pitch, 1 Row, Shrouded

Bulk discount available

View bulk pricing options

Subtotal (1 bag of 5 units)*

£19.77

(exc. VAT)

£23.72

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

Plus 400 unit(s) shipping from 17 June 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Bag(s)	Per Bag	Per unit*
1 - 4	£19.77	£3.954
5 +	£18.19	£3.638

*price indicative

RS Stock No.:: 631-127
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Product Type	PCB Header
	Series	XY103
	Current	10A
	Pitch	5mm
	Number of Contacts	4
	Housing Material	PA66
	Number of Rows	1
	Orientation	45°
	Shrouded/Unshrouded	Shrouded
	Mount Type	Through Hole
	Connector System	Board-to-Board, Board-to-Wire
	Contact Material	Brass
	Contact Plating	Tin
	Termination Type	Screw
	Minimum Operating Temperature	-40°C
	Contact Gender	Male
	Tail Pin Length	3.8mm
	Maximum Operating Temperature	105°C
	Standards/Approvals	ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
	Voltage	250, 300V

	Select all
	Brand RS PRO
	Product Type PCB Header
	Series XY103
	Current 10A
	Pitch 5mm
	Number of Contacts 4
	Housing Material PA66
	Number of Rows 1
	Orientation 45°
	Shrouded/Unshrouded Shrouded
	Mount Type Through Hole
	Connector System Board-to-Board, Board-to-Wire
	Contact Material Brass
	Contact Plating Tin
	Termination Type Screw
	Minimum Operating Temperature -40°C
	Contact Gender Male
	Tail Pin Length 3.8mm
	Maximum Operating Temperature 105°C
	Standards/Approvals ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
	Voltage 250, 300V

COO (Country of Origin):: CN

RS PRO 4-Pin Shrouded PCB Header, 5mm Pitch

This RS PRO PCB Header is designed for reliable electrical connections in various industrial applications. With a robust build and versatile connection system, it ensures efficient power and signal transmission. Ideal for use in environments requiring secure and stable connections.

Features and Benefits

Board-to-Board and Board-to-Wire System: Offers flexibility in connection types, enhancing application versatility
Male Contact Gender: Ensures compatibility with a wide range of connectors
Brass Contact Material with Tin Plating: Provides excellent conductivity and corrosion resistance
10 A Current Rating: Supports high power applications
PA66 Housing Material: Offers durability and resistance to environmental factors
Operating Temperature Range -40 °C to 105 °C: Suitable for use in extreme temperature conditions
Through Hole Mount Type: Ensures secure and stable mounting on PCBs
Shrouded Design: Provides protection against accidental contact and damage
Screw Termination Type: Allows for secure and reliable connections
Compliance with ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE: Meets international safety and quality standards

Applications

Industrial automation
Consumer electronics
Telecommunications
Power distribution systems

Additional Information

Standards Approvals: ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
Voltage Rating: 250 V VDE, 300 V UL
Pitch: 5 mm
Tail Pin Length: 3.8 mm
