RS PRO XY301V Series Straight Through Hole PCB Header, 4 Contact(s), 5 mm Pitch, 1 Row, Shrouded

RS Stock No.:: 631-125
Brand:: RS PRO

RS PRO XY301V Series Straight Through Hole PCB Header, 4 Contact(s), 5 mm Pitch, 1 Row, Shrouded

Bulk discount available

View bulk pricing options

Subtotal (1 bag of 5 units)*

£8.34

(exc. VAT)

£10.01

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

385 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Bag(s)	Per Bag	Per unit*
1 - 4	£8.34	£1.668
5 - 9	£7.67	£1.534
10 +	£6.92	£1.384

*price indicative

RS Stock No.:: 631-125
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Product Type	PCB Header
	Series	XY301V
	Pitch	5mm
	Current	16A
	Number of Contacts	4
	Housing Material	PBT
	Number of Rows	1
	Orientation	Straight
	Shrouded/Unshrouded	Shrouded
	Connector System	Board-to-Board, Board-to-Wire
	Mount Type	Through Hole
	Contact Material	Brass
	Contact Plating	Tin
	Termination Type	Screw
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	105°C
	Tail Pin Length	4.2mm
	Contact Gender	Male
	Standards/Approvals	ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
	Voltage	250, 300V

	Select all
	Brand RS PRO
	Product Type PCB Header
	Series XY301V
	Pitch 5mm
	Current 16A
	Number of Contacts 4
	Housing Material PBT
	Number of Rows 1
	Orientation Straight
	Shrouded/Unshrouded Shrouded
	Connector System Board-to-Board, Board-to-Wire
	Mount Type Through Hole
	Contact Material Brass
	Contact Plating Tin
	Termination Type Screw
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 105°C
	Tail Pin Length 4.2mm
	Contact Gender Male
	Standards/Approvals ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
	Voltage 250, 300V

COO (Country of Origin):: CN

RS PRO 4 Contact PCB Header, Shrouded, 5 mm Pitch

This RS PRO PCB Header is designed for reliable electrical connections in board-to-board and board-to-wire applications. With a robust current rating of 16 A, it is Ideal for high-performance environments requiring secure and efficient connectivity.

Features and Benefits

Board-to-Board and Board-to-Wire System: Offers versatile connectivity options for various applications
Male Contact Gender: Ensures compatibility with female connectors for secure connections
Brass Contact Material with Tin Plating: Provides excellent conductivity and corrosion resistance
PBT Housing Material: Offers durability and resistance to high temperatures
Wide Operating Temperature Range (-40 °C to 105 °C): Suitable for use in diverse environmental conditions
Through Hole Mount Type: Ensures stable and reliable mounting on PCBs
Shrouded Design: Provides protection against accidental contact and enhances safety
Screw Termination Type: Facilitates easy and secure wire connections

Applications

Industrial automation
Consumer electronics
Telecommunications
Automotive systems

Additional Information

Complies with ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, and VDE standards
Rated for 250 V VDE and 300 V UL, ensuring compatibility with various voltage requirements
Features a 5 mm pitch and 4.2 mm tail pin length for precise PCB integration

Why RS PRO?

RS PRO is the own brand of RS, offering professional quality products and solutions across all industries and technologies. Our product range is rigorously tested, inspected, and audited against demanding international standards to provide you with industrial-grade quality, at the right price. Making RS PRO your smart choice.
