RS PRO XY300V Series Straight Through Hole PCB Header, 3 Contact(s), 5 mm Pitch, 1 Row, Shrouded

RS Stock No.:: 631-130
Brand:: RS PRO

RS PRO XY300V Series Straight Through Hole PCB Header, 3 Contact(s), 5 mm Pitch, 1 Row, Shrouded

Bulk discount available

View bulk pricing options

Subtotal (1 bag of 5 units)*

£6.55

(exc. VAT)

£7.86

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

118 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Bag(s)	Per Bag	Per unit*
1 - 4	£6.55	£1.31
5 - 9	£6.03	£1.206
10 +	£5.43	£1.086

*price indicative

RS Stock No.:: 631-130
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Series	XY300V
	Product Type	PCB Header
	Pitch	5mm
	Current	16A
	Number of Contacts	3
	Housing Material	PBT
	Number of Rows	1
	Orientation	Straight
	Shrouded/Unshrouded	Shrouded
	Connector System	Board-to-Board, Board-to-Wire
	Mount Type	Through Hole
	Contact Plating	Tin
	Contact Material	Brass
	Minimum Operating Temperature	-40°C
	Termination Type	Screw
	Contact Gender	Male
	Tail Pin Length	4.2mm
	Maximum Operating Temperature	105°C
	Standards/Approvals	ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
	Voltage	300V

	Select all
	Brand RS PRO
	Series XY300V
	Product Type PCB Header
	Pitch 5mm
	Current 16A
	Number of Contacts 3
	Housing Material PBT
	Number of Rows 1
	Orientation Straight
	Shrouded/Unshrouded Shrouded
	Connector System Board-to-Board, Board-to-Wire
	Mount Type Through Hole
	Contact Plating Tin
	Contact Material Brass
	Minimum Operating Temperature -40°C
	Termination Type Screw
	Contact Gender Male
	Tail Pin Length 4.2mm
	Maximum Operating Temperature 105°C
	Standards/Approvals ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
	Voltage 300V

COO (Country of Origin):: CN

RS PRO PCB Header, 3 Contacts, 5 mm Pitch, 16 A

This RS PRO PCB Header is designed for reliable electrical connections in various industrial applications. With a robust construction, it supports both board-to-board and board-to-wire connections, making it versatile for different setups. The shrouded design ensures secure mating and protection against accidental disconnection.

Features and Benefits

Board-to-Board and Board-to-Wire Compatibility: Offers flexibility in connection types for diverse applications
Male Contacts: Ensures a secure and stable connection
Brass Contacts with Tin Plating: Provides excellent conductivity and corrosion resistance
16 A Current Rating: Suitable for high-power applications
PBT Housing Material: Offers durability and resistance to high temperatures
Wide Operating Temperature Range (-40 °C to 105 °C): Suitable for harsh environments
Through Hole Mount Type: Ensures strong mechanical stability on the PCB
Shrouded Design: Protects contacts and ensures proper alignment
Screw Termination: Facilitates easy and secure wire connections

Applications

Industrial automation
Consumer electronics
Telecommunications
Power distribution systems

Additional Information

Complies with ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE standards
Rated for 300 V applications
Tail pin length of 4.2 mm for secure PCB mounting
