RS PRO XY301V Series Straight Through Hole PCB Header, 3 Contact(s), 5 mm Pitch, 1 Row, Shrouded

RS Stock No.:: 631-124
Brand:: RS PRO

RS PRO XY301V Series Straight Through Hole PCB Header, 3 Contact(s), 5 mm Pitch, 1 Row, Shrouded

Bulk discount available

View bulk pricing options

Subtotal (1 bag of 5 units)*

£6.51

(exc. VAT)

£7.81

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

391 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Bag(s)	Per Bag	Per unit*
1 - 4	£6.51	£1.302
5 - 9	£5.99	£1.198
10 +	£5.40	£1.08

*price indicative

RS Stock No.:: 631-124
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Series	XY301V
	Product Type	PCB Header
	Pitch	5mm
	Current	16A
	Housing Material	PBT
	Number of Contacts	3
	Number of Rows	1
	Orientation	Straight
	Shrouded/Unshrouded	Shrouded
	Mount Type	Through Hole
	Connector System	Board-to-Board, Board-to-Wire
	Contact Material	Brass
	Contact Plating	Tin
	Termination Type	Screw
	Minimum Operating Temperature	-40°C
	Contact Gender	Male
	Tail Pin Length	4.2mm
	Maximum Operating Temperature	105°C
	Standards/Approvals	ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
	Voltage	250, 300V

	Select all
	Brand RS PRO
	Series XY301V
	Product Type PCB Header
	Pitch 5mm
	Current 16A
	Housing Material PBT
	Number of Contacts 3
	Number of Rows 1
	Orientation Straight
	Shrouded/Unshrouded Shrouded
	Mount Type Through Hole
	Connector System Board-to-Board, Board-to-Wire
	Contact Material Brass
	Contact Plating Tin
	Termination Type Screw
	Minimum Operating Temperature -40°C
	Contact Gender Male
	Tail Pin Length 4.2mm
	Maximum Operating Temperature 105°C
	Standards/Approvals ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE
	Voltage 250, 300V

COO (Country of Origin):: CN

RS PRO 3-Pin Shrouded PCB Header, 16 A, 5 mm Pitch

The RS PRO PCB Header is designed for reliable electrical connections in various electronic applications. With a robust construction, it supports both board-to-board and board-to-wire connections, making it versatile for different setups. Its shrouded design ensures secure mating and protection against accidental disconnection.

Features and Benefits

Board-to-Board and Board-to-Wire Compatibility: Offers flexibility in connection types for diverse applications.
Male Brass Contacts with Tin Plating: Ensures excellent conductivity and corrosion resistance.
16 A Current Rating: Suitable for high-power applications, providing reliable performance.
PBT Housing Material: Provides durability and resistance to high temperatures and chemicals.
Wide Operating Temperature Range (-40 °C to 105 °C): Suitable for use in various environmental conditions.
Through Hole Mount Type: Ensures secure and stable mounting on PCBs.
Shrouded Design: Protects contacts and ensures secure connections.
Standards Compliant (ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL, VDE): Meets international safety and quality standards.

Applications

Industrial automation
Consumer electronics
Telecommunications
Automotive electronics

Additional Information

Termination Type: Screw
Voltage Rating: 250 V VDE, 300 V UL
Tail Pin Length: 4.2 mm
This PCB header is Ideal for engineers and technicians looking for a reliable and compliant solution for their electronic connection needs.
