TE Connectivity AMPMODU Series Vertical Board PCB Header, 2 Contact(s), 2.54 mm Pitch, 1 Row, Unshrouded
- RS Stock No.:
- 508-985
- Distrelec Article No.:
- 304-64-121
- Mfr. Part No.:
- 826648-2
- Brand:
- TE Connectivity
Subtotal (1 pack of 450 units)*
£166.50
(exc. VAT)
£199.80
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 17 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £166.50 | £0.37 |
*price indicative
- RS Stock No.:
- 508-985
- Distrelec Article No.:
- 304-64-121
- Mfr. Part No.:
- 826648-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | AMPMODU | |
| Product Type | PCB Header | |
| Current | 5A | |
| Pitch | 2.54mm | |
| Housing Material | Polybutylene Terephthalate | |
| Number of Contacts | 2 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Unshrouded | |
| Connector System | Board-to-Board | |
| Mount Type | Board | |
| Contact Plating | Tin | |
| Contact Material | Phosphor Bronze | |
| Termination Type | Solder | |
| Row Pitch | 2.54mm | |
| Minimum Operating Temperature | 65°C | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 3.2mm | |
| Standards/Approvals | China RoHS 2, EU ELV, EU RoHS, UL 94V-0 | |
| Voltage | 750 Vrms | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series AMPMODU | ||
Product Type PCB Header | ||
Current 5A | ||
Pitch 2.54mm | ||
Housing Material Polybutylene Terephthalate | ||
Number of Contacts 2 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Unshrouded | ||
Connector System Board-to-Board | ||
Mount Type Board | ||
Contact Plating Tin | ||
Contact Material Phosphor Bronze | ||
Termination Type Solder | ||
Row Pitch 2.54mm | ||
Minimum Operating Temperature 65°C | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 3.2mm | ||
Standards/Approvals China RoHS 2, EU ELV, EU RoHS, UL 94V-0 | ||
Voltage 750 Vrms | ||
- COO (Country of Origin):
- PL
The TE Connectivity Mount Header is engineered to facilitate smooth and efficient board-to-board connections. Designed for vertical mounting, this component features a compact 2-position configuration on a standard 2.54 mm centreline, making it ideal for applications where space is at a premium. Built for durability, this header incorporates breakaway functionality, ensuring versatility during installation and maintenance. The AMPMODU series combines reliability with performance, featuring robust electrical characteristics to accommodate various signal circuit applications. Its premium materials and comprehensive compliance with industry standards signify confidence in quality and safety, making it a go-to choice for modern electronics designs.
Optimised for reliable board-to-board connections
Compact design enhances space efficiency in electronic layouts
Breakaway capability provides installation flexibility
Robust electrical performance tailored for signal applications
High-quality materials improve durability and longevity
Meets stringent industry standards for safety and quality assurance
Standard centreline promotes compatibility with existing designs
