TE Connectivity AMPMODU Series Vertical Board PCB Header, 24 Contact(s), 2.54 mm Pitch, 2 Row(s), Unshrouded

View all PCB Headers

Subtotal (1 box of 90 units)*

£170.85

(exc. VAT)

£205.02

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 02 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es)
Per Box
Per unit*
1 +£170.85£1.898

*price indicative

RS Stock No.:
472-847
Mfr. Part No.:
1-826632-2
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Series

AMPMODU

Product Type

PCB Header

Pitch

2.54mm

Current

5A

Number of Contacts

24

Housing Material

Polybutylene Terephthalate

Number of Rows

2

Orientation

Vertical

Shrouded/Unshrouded

Unshrouded

Mount Type

Board

Connector System

Board-to-Board

Contact Material

Phosphor Bronze

Contact Plating

Gold Flash over Nickel

Row Pitch

2.54mm

Minimum Operating Temperature

65°C

Termination Type

Solder

Maximum Operating Temperature

105°C

Tail Pin Length

3.2mm

Standards/Approvals

UL 94 V-0

Voltage

750 Vrms

Distrelec Product Id

304-50-164

COO (Country of Origin):
PL
The TE Connectivity PCB Mount Header, designed for vertical board-to-board connectivity, offers a high-performance solution for intricate electronic systems. This versatile 24-position header seamlessly accommodates a 2.54 mm centreline spacing, making it ideal for dense PCB layouts. Known for its breakaway feature, the connector ensures flexibility in applications where adaptability is crucial. Crafted to withstand demanding conditions, this component combines durability and efficiency, enhancing connection reliability in various environments. The insulation resistance and dielectric withstanding voltage specifications further highlight its robust construction, catering to professional electronic assembly requirements. Whether for industrial, automotive, or consumer applications, this header guarantees excellent signal integrity and reliability.

Delivers reliable board-to-board connections in vertical orientation

Breakaway design enables adaptability for different configurations

Constructed to meet high insulation resistance standards

Engineered with nickel underplating for enhanced contact reliability

Compatible with a range of PCB thicknesses for versatile applications

Designed for fully loaded configurations to maximise performance

Highly resistant to operating temperatures ranging from -65 to 105 °C

Supports wave soldering processes for efficient assembly

Compliant with EU RoHS and ELV directives for environmental safety

Utilises PBT housing material for superior mechanical stability
