TE Connectivity 5-102 Series Right Angle Board PCB Header, 5 Contact(s), 2.54 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 481-063
- Mfr. Part No.:
- 5-102203-2
- Brand:
- TE Connectivity
Subtotal (1 tube of 102 units)*
£173.39
(exc. VAT)
£208.07
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £173.39 | £1.70 |
*price indicative
- RS Stock No.:
- 481-063
- Mfr. Part No.:
- 5-102203-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Header | |
| Series | 5-102 | |
| Current | 3A | |
| Pitch | 2.54mm | |
| Housing Material | Thermoplastic | |
| Number of Contacts | 5 | |
| Number of Rows | 1 | |
| Orientation | Right Angle | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Board | |
| Connector System | Board-to-Board | |
| Contact Plating | Gold | |
| Contact Material | Phosphor Bronze | |
| Minimum Operating Temperature | 65°C | |
| Termination Type | Solder | |
| Row Pitch | 2.54mm | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 2.79mm | |
| Standards/Approvals | CSA LR7189, UL 94V-0, UL E28476 | |
| Voltage | 750 Vrms | |
| Distrelec Product Id | 304-52-005 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Header | ||
Series 5-102 | ||
Current 3A | ||
Pitch 2.54mm | ||
Housing Material Thermoplastic | ||
Number of Contacts 5 | ||
Number of Rows 1 | ||
Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Board | ||
Connector System Board-to-Board | ||
Contact Plating Gold | ||
Contact Material Phosphor Bronze | ||
Minimum Operating Temperature 65°C | ||
Termination Type Solder | ||
Row Pitch 2.54mm | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 2.79mm | ||
Standards/Approvals CSA LR7189, UL 94V-0, UL E28476 | ||
Voltage 750 Vrms | ||
Distrelec Product Id 304-52-005 | ||
- COO (Country of Origin):
- MX
The TE Connectivity PCB Mount Header is a meticulously engineered connector designed for reliable board-to-board connections. This right-angle assembly features five positions and a compact 2.54 mm centreline, making it ideal for applications where space is at a premium. Constructed with a fully shrouded header and gold-plated contacts, it ensures optimal conductivity and longevity. Its robust design allows for a secure connection, while also accommodating high insulation resistance and dielectric strength requirements. This product is purpose-built for modern electronic applications, ensuring dependable performance in challenging environments and supporting vibrations without compromising integrity.
Compact design optimised for high-density applications
Fully shrouded header enhances safety and connection reliability
Gold plating provides superior conductivity and resistance to corrosion
Rated for a wide operating temperature range, ensuring versatile usage
Compatible with wave soldering processes for efficient assembly
Polarised mating alignment ensures correct orientation during installation
Suitable for signal circuit applications, enhancing performance in communication systems
