TE Connectivity AMPMODU Series Right Angle Board PCB Header, 84 Contact(s), 2.54 mm Pitch, 2 Row(s)

View all PCB Headers

Subtotal (1 unit)*

£346.54

(exc. VAT)

£415.85

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 09 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£346.54

*price indicative

RS Stock No.:
472-409
Mfr. Part No.:
4-87964-1
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Product Type

PCB Header

Series

AMPMODU

Pitch

2.54mm

Number of Contacts

84

Housing Material

Polyphenylene Sulphide

Number of Rows

2

Orientation

Right Angle

Connector System

Board-to-Board

Mount Type

Board

Contact Plating

Gold

Contact Material

Phosphor Bronze

Minimum Operating Temperature

65°C

Termination Type

Solder

Row Pitch

2.54mm

Tail Pin Length

3.68mm

Maximum Operating Temperature

125°C

Standards/Approvals

2016, China RoHS 2 MIIT Order No 32, EU ELV 2000/53/EC, EU RoHS 2011/65/EU

Distrelec Product Id

303-31-881

COO (Country of Origin):
US
The TE Connectivity PCB Mount Receptacle is an innovative connector designed for efficient board-to-board applications, offering superior performance with its right-angle orientation. Its 84 positions accommodate complex configurations, while the 2.54 mm centreline ensures compatibility with standard PCB layouts. This connector features a reliable header and push-push assembly, making it ideal for applications requiring secure and uncomplicated connections. With gold plating for enhanced conductivity and longevity, this receptacle is tailored for demanding signal applications, ensuring that it meets the robust operational needs of modern electronic devices. Its design considers thermal management and functionality, providing outstanding reliability within an operating temperature range that spans from -65°C to 125°C.

Designed for efficient board-to-board connectivity

Offers a compact solution with 84 positions in two rows

Features a reliable centreline of 2.54 mm for compatibility with standard PCBs

Constructed with high-quality materials to ensure durability

Incorporates a closed entry housing for enhanced contact protection

Allows for easy soldering through its through-hole termination method

Optimised for use in signal applications for improved performance

Provides reliable mating alignment using centre and dual alignment types

Constructed with polyphenylene sulfide for excellent thermal stability

Features gold flashing for superior conductivity in contact areas
