Microchip LND250 N-Channel DMOS FET-Channel Single MOSFETs, 350 mA, 9 V Depletion Mode, 5-Pin SOT-23-5 LND250K1-G
- RS Stock No.:
- 598-794
- Mfr. Part No.:
- LND250K1-G
- Brand:
- Microchip
Subtotal (1 reel of 3000 units)*
£2,028.00
(exc. VAT)
£2,433.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 3000 + | £0.676 | £2,028.00 |
*price indicative
- RS Stock No.:
- 598-794
- Mfr. Part No.:
- LND250K1-G
- Brand:
- Microchip
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Microchip | |
| Product Type | Single MOSFETs | |
| Channel Type | N-Channel DMOS FET | |
| Maximum Continuous Drain Current Id | 350mA | |
| Maximum Drain Source Voltage Vds | 9V | |
| Package Type | SOT-23-5 | |
| Series | LND250 | |
| Mount Type | Surface | |
| Pin Count | 5 | |
| Maximum Drain Source Resistance Rds | 1.4Ω | |
| Channel Mode | Depletion Mode | |
| Minimum Operating Temperature | -25°C | |
| Maximum Power Dissipation Pd | 360mW | |
| Maximum Gate Source Voltage Vgs | 12 V | |
| Forward Voltage Vf | 1.8V | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | RoHS, ISO/TS‑16949 | |
| Height | 1.3mm | |
| Width | 1.75 mm | |
| Length | 3.05mm | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Microchip | ||
Product Type Single MOSFETs | ||
Channel Type N-Channel DMOS FET | ||
Maximum Continuous Drain Current Id 350mA | ||
Maximum Drain Source Voltage Vds 9V | ||
Package Type SOT-23-5 | ||
Series LND250 | ||
Mount Type Surface | ||
Pin Count 5 | ||
Maximum Drain Source Resistance Rds 1.4Ω | ||
Channel Mode Depletion Mode | ||
Minimum Operating Temperature -25°C | ||
Maximum Power Dissipation Pd 360mW | ||
Maximum Gate Source Voltage Vgs 12 V | ||
Forward Voltage Vf 1.8V | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals RoHS, ISO/TS‑16949 | ||
Height 1.3mm | ||
Width 1.75 mm | ||
Length 3.05mm | ||
Automotive Standard No | ||
- COO (Country of Origin):
- TH
The Microchip High voltage N-channel depletion mode (normally-on) transistor utilizing lateral DMOS technology. The gate is ESD protected. The LND250 is ideal for high voltage applications in the areas of normally-on switches, precision constant current sources, voltage ramp generation and amplification.
Free from secondary breakdown
Low power drive requirement
Ease of paralleling
Excellent thermal stability
Integral source drain diode
High input impedance and low CISS
ESD gate protection
