TE Connectivity AMPLIMITE 9 Way Vertical 2.77 mm Pitch Board D-Sub Connector Female
- RS Stock No.:
- 474-970
- Distrelec Article No.:
- 304-48-690
- Mfr. Part No.:
- 1757829-1
- Brand:
- TE Connectivity
Subtotal (1 pack of 7 units)*
£151.51
(exc. VAT)
£181.81
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 22 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £151.51 | £21.644 |
*price indicative
- RS Stock No.:
- 474-970
- Distrelec Article No.:
- 304-48-690
- Mfr. Part No.:
- 1757829-1
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | D-Sub Connector | |
| Number of Contacts | 9 | |
| Orientation | Vertical | |
| Current | 5A | |
| Mount Type | Board | |
| Connector Gender | Female | |
| Connector Type D | D-Sub | |
| D-Sub Shell Size | 1 | |
| Housing Material | Steel | |
| Minimum Operating Temperature | -55°C | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 125°C | |
| Contact Gender | Female | |
| Standards/Approvals | China RoHS 2 MIIT Order No 32, EU ELV 2000/53/EC, EU REACH (EC) No. 1907/2006, 2016 Restricted Materials Above Threshold, EU RoHS 2011/65/EU | |
| Contact Material | Brass, Beryllium Copper Alloy | |
| Contact Plating | Gold | |
| Series | AMPLIMITE | |
| Contact Size | 20 | |
| Pitch | 2.77mm | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type D-Sub Connector | ||
Number of Contacts 9 | ||
Orientation Vertical | ||
Current 5A | ||
Mount Type Board | ||
Connector Gender Female | ||
Connector Type D D-Sub | ||
D-Sub Shell Size 1 | ||
Housing Material Steel | ||
Minimum Operating Temperature -55°C | ||
Termination Type Solder | ||
Maximum Operating Temperature 125°C | ||
Contact Gender Female | ||
Standards/Approvals China RoHS 2 MIIT Order No 32, EU ELV 2000/53/EC, EU REACH (EC) No. 1907/2006, 2016 Restricted Materials Above Threshold, EU RoHS 2011/65/EU | ||
Contact Material Brass, Beryllium Copper Alloy | ||
Contact Plating Gold | ||
Series AMPLIMITE | ||
Contact Size 20 | ||
Pitch 2.77mm | ||
- COO (Country of Origin):
- MX
The TE Connectivity cable-to-board connector is engineered to deliver exceptional performance in demanding applications. Designed specifically for board mounting, this plug features a 9-position configuration that ensures robust signal integrity and reliability. The connector is constructed with durable steel and zinc materials, allowing it to endure harsh environments while providing secure connections for electronic circuits. Its vertical PCB mount orientation optimises board space usage, making it a practical choice for modern electronic designs. With a centreline spacing of 2.77 mm, it’s ideal for applications requiring compact arrangements. The combination of gold-plated contacts and a reliable soldering method further enhances its functionality, making this connector a go-to solution for signal applications in various electronic assemblies.
Constructed from steel for enhanced durability
Gold-plated contacts ensure superior conductivity
Compatible with through-hole solder termination for easy assembly
Vertical PCB mount orientation maximises available space
Active status signifies reliable availability for production needs
Meets compliance standards for environmental safety, including RoHS and REACH
Capable of operation within a wide temperature range from -55 to 125 °C
