TE Connectivity CGS TLR 0.003 Ω, 2512 Current Sensing Surface Mount Resistor 1 % Surface 1 W - 3-1879378-2
- RS Stock No.:
- 481-229
- Distrelec Article No.:
- 304-51-903
- Mfr. Part No.:
- 3-1879378-2
- Brand:
- TE Connectivity
Subtotal (1 reel of 2000 units)*
£636.00
(exc. VAT)
£764.00
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 14 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 2000 + | £0.318 | £636.00 |
*price indicative
- RS Stock No.:
- 481-229
- Distrelec Article No.:
- 304-51-903
- Mfr. Part No.:
- 3-1879378-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | Surface Mount Resistor | |
| Resistance | 0.003Ω | |
| Resistor Type | Current | |
| Technology | Current Sensing | |
| Package/Case | 2512 | |
| Packaging | Tape & Reel | |
| Tolerance | 1 % | |
| Power Rating | 1W | |
| Mount Type | Surface | |
| Temperature Coefficient | ±150 ppm/°C | |
| Automotive Standard | No | |
| Series | CGS TLR | |
| Maximum Operating Temperature | 260°C | |
| Standards/Approvals | 2016 Compliant, China RoHS 2 Directive MIIT Order No 32, EU ELV Directive 2000/53/EC Compliant, EU REACH Regulation (EC) No. 1907/2006, EU RoHS Directive 2011/65/EU Compliant | |
| Height | 0.55mm | |
| Length | 6.35mm | |
| Width | 3.18mm | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type Surface Mount Resistor | ||
Resistance 0.003Ω | ||
Resistor Type Current | ||
Technology Current Sensing | ||
Package/Case 2512 | ||
Packaging Tape & Reel | ||
Tolerance 1 % | ||
Power Rating 1W | ||
Mount Type Surface | ||
Temperature Coefficient ±150 ppm/°C | ||
Automotive Standard No | ||
Series CGS TLR | ||
Maximum Operating Temperature 260°C | ||
Standards/Approvals 2016 Compliant, China RoHS 2 Directive MIIT Order No 32, EU ELV Directive 2000/53/EC Compliant, EU REACH Regulation (EC) No. 1907/2006, EU RoHS Directive 2011/65/EU Compliant | ||
Height 0.55mm | ||
Length 6.35mm | ||
Width 3.18mm | ||
- COO (Country of Origin):
- TW
The TE Connectivity surface mount current sensing resistor is engineered to deliver exceptional performance in compact applications. With its innovative metal strip design, the product offers a resistance value of 0.003 ohm, ensuring precise current measurement. Ideal for environments requiring high thermal stability, it has a power rating of 1 W and maintains accuracy over a wide temperature range with a coefficient of ±150 ppm/°C. The tapered and reeled packaging facilitates easy integration into automated assembly processes. Suitable for a variety of consumer and industrial electronics, its robust features make it a reliable choice for engineers seeking quality and efficiency in current sensing.
Designed for high reliability in demanding applications
Efficient in size with a 2512 package footprint
Provides outstanding thermal stability and performance
Supports automated assembly with taped and reeled packaging
Low halogen content enhances environmental compliance
Features a solder termination type for seamless integration
