TE Connectivity AMP HPI Series Right Angle Board PCB Header, 8 Contact(s), 2.5 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 477-303
- Mfr. Part No.:
- 440053-8
- Brand:
- TE Connectivity
Subtotal (1 pack of 200 units)*
£188.31
(exc. VAT)
£225.97
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £188.31 | £0.942 |
*price indicative
- RS Stock No.:
- 477-303
- Mfr. Part No.:
- 440053-8
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | AMP HPI | |
| Product Type | PCB Header | |
| Current | 3A | |
| Pitch | 2.5mm | |
| Number of Contacts | 8 | |
| Housing Material | Polyamide 66 Fibreglass | |
| Number of Rows | 1 | |
| Orientation | Right Angle | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Board | |
| Connector System | Wire-to-Board | |
| Contact Material | Brass | |
| Contact Plating | Tin Plated | |
| Minimum Operating Temperature | -25°C | |
| Row Pitch | 2.5mm | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 85°C | |
| Tail Pin Length | 3.4mm | |
| Standards/Approvals | UL 94 V-0 | |
| Mating Pin Length | 4mm | |
| Voltage | 250 V | |
| Distrelec Product Id | 304-54-114 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series AMP HPI | ||
Product Type PCB Header | ||
Current 3A | ||
Pitch 2.5mm | ||
Number of Contacts 8 | ||
Housing Material Polyamide 66 Fibreglass | ||
Number of Rows 1 | ||
Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Board | ||
Connector System Wire-to-Board | ||
Contact Material Brass | ||
Contact Plating Tin Plated | ||
Minimum Operating Temperature -25°C | ||
Row Pitch 2.5mm | ||
Termination Type Solder | ||
Maximum Operating Temperature 85°C | ||
Tail Pin Length 3.4mm | ||
Standards/Approvals UL 94 V-0 | ||
Mating Pin Length 4mm | ||
Voltage 250 V | ||
Distrelec Product Id 304-54-114 | ||
- COO (Country of Origin):
- CN
The TE Connectivity PCB Mount Header is engineered for efficient wire-to-board applications, optimising connections in various electronic systems. Designed with a right-angle orientation and featuring eight positions, it ensures seamless integration into your printed circuit boards. This connector's partially shrouded header, with a pitch of 2.5 mm, facilitates straightforward soldering and a secure fit. Its robust construction, combining nylon 66 GF housing and brass contact components, guarantees durability and reliability under a range of operating conditions. With a commendable operating voltage of 250 VDC and operating temperature range from -25°C to 85°C, this connector can perform effectively in diverse environments, ensuring your circuits maintain their integrity and functionality.
Right-angle configuration simplifies board layout and space utilisation
Partially shrouded design minimises potential for misalignment during mating
Bright plating finish on contact mating area enhances connection reliability
Nylon 66 GF housing provides excellent thermal and mechanical resistance
Able to accommodate three terminations per post for efficient connectivity
Compatibility with through-hole soldering for greater design versatility
A high contact current rating of 3 A ensures robust electrical performance
Polarisation features aid in accurate mating and prevent connection errors
