Quad Silicon N-Channel MOSFET, 5 A, 850 V, 3-Pin D2PAK Vishay SIHB6N80AE-GE3
- RS Stock No.:
- 268-8294
- Mfr. Part No.:
- SIHB6N80AE-GE3
- Brand:
- Vishay
Available to back order for despatch 27/01/2025
Price Each (In a Tube of 50)
£1.095
(exc. VAT)
£1.314
(inc. VAT)
Units | Per unit | Per Tube* |
|---|---|---|
| 50 - 50 | £1.095 | £54.75 |
| 100 - 450 | £0.882 | £44.10 |
| 500 + | £0.722 | £36.10 |
*price indicative
- RS Stock No.:
- 268-8294
- Mfr. Part No.:
- SIHB6N80AE-GE3
- Brand:
- Vishay
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
The Vishay E series power MOSFET has low switching and conduction losses, it is used in applications such as switch mode power supplies, server power supplies, and power factor correction power supplies. It has integrated zener diode for ESD protection.
Low effective capacitance
Avalanche energy rated
Low figure of merit
Avalanche energy rated
Low figure of merit
Specifications
Attribute | Value |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 5 A |
| Maximum Drain Source Voltage | 850 V |
| Package Type | TO-263 |
| Mounting Type | Surface Mount |
| Pin Count | 3 |
| Channel Mode | Enhancement |
| Number of Elements per Chip | 4 |
| Transistor Material | Silicon |
