Name: Infineon OptiMOS SiC N-Channel MOSFET, 454 A, 60 V, 16-Pin PG-HDSOP-16 IPTC007N06NM5ATMA1
Brand: Infineon
SKU: 284-691
Price: 5.11 GBP
Availability: OutOfStock

The Infineon MOSFET features an OptiMOS 5 Power Transistor is engineered for high performance applications in motor drives and battery powered systems. This device excels with its robust 60V rating and outstanding thermal performance, ensuring reliability in demanding environments. With features optimised for top side cooling, this transistor delivers high current capabilities while maintaining efficiency under stiff operational standards. Fully qualified according to JEDEC for industrial applications, it surpasses 100% avalanche testing criteria, guaranteeing resilience against unexpected conditions. The PG HDSOP 16 package design not only fosters enhanced cooling but also aids in space efficient integration within various designs.

Optimised for efficient motor drives
N Channel design for easy integration
Pb free lead plating meets environmental standards
Halogen free for safer lifecycle management
Rated 175°C for enhanced reliability
100% avalanche tested for security
Superior thermal management extends lifespan
Compatible with industry standard packaging

Select all	Attribute	Value
	Brand	Infineon
	Channel Type	N
	Maximum Continuous Drain Current	454 A
	Maximum Drain Source Voltage	60 V
	Package Type	PG-HDSOP-16
	Series	OptiMOS
	Mounting Type	Surface Mount
	Pin Count	16
	Channel Mode	Enhancement
	Number of Elements per Chip	1
	Transistor Material	SiC

	Select all
	Brand Infineon
	Channel Type N
	Maximum Continuous Drain Current 454 A
	Maximum Drain Source Voltage 60 V
	Package Type PG-HDSOP-16
	Series OptiMOS
	Mounting Type Surface Mount
	Pin Count 16
	Channel Mode Enhancement
	Number of Elements per Chip 1
	Transistor Material SiC

Infineon OptiMOS SiC N-Channel MOSFET, 454 A, 60 V, 16-Pin PG-HDSOP-16 IPTC007N06NM5ATMA1
