Arcol Ohmite HS100 60R F, 60 Ω 100 W Wirewound Wirewound Fixed Resistor ±1 %
- RS Stock No.:
- 285-8222
- Distrelec Article No.:
- 302-47-418
- Mfr. Part No.:
- HS100 60R F
- Brand:
- Arcol Ohmite
Subtotal (1 unit)*
£10.06
(exc. VAT)
£12.07
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 45 unit(s) shipping from 17 February 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £10.06 |
*price indicative
- RS Stock No.:
- 285-8222
- Distrelec Article No.:
- 302-47-418
- Mfr. Part No.:
- HS100 60R F
- Brand:
- Arcol Ohmite
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Arcol Ohmite | |
| Resistance | 60Ω | |
| Product Type | Wirewound Fixed Resistor | |
| Power Rating | 100W | |
| Series | HS100 | |
| Package/Case | Aluminium | |
| Temperature Coefficient | 100 ppm/°C | |
| Tolerance | ±1 % | |
| Automotive Standard | No | |
| Technology | Wirewound | |
| Termination Style | Soldering connection | |
| Minimum Operating Temperature | -55°C | |
| Overall Length | 88mm | |
| Maximum Operating Temperature | 200°C | |
| Overall Height | 47.5mm | |
| Standards/Approvals | IEC 115, MIL 18546, RoHS | |
| Overall Width | 27.5mm | |
| Overall Diameter | 27.3mm | |
| Select all | ||
|---|---|---|
Brand Arcol Ohmite | ||
Resistance 60Ω | ||
Product Type Wirewound Fixed Resistor | ||
Power Rating 100W | ||
Series HS100 | ||
Package/Case Aluminium | ||
Temperature Coefficient 100 ppm/°C | ||
Tolerance ±1 % | ||
Automotive Standard No | ||
Technology Wirewound | ||
Termination Style Soldering connection | ||
Minimum Operating Temperature -55°C | ||
Overall Length 88mm | ||
Maximum Operating Temperature 200°C | ||
Overall Height 47.5mm | ||
Standards/Approvals IEC 115, MIL 18546, RoHS | ||
Overall Width 27.5mm | ||
Overall Diameter 27.3mm | ||
- COO (Country of Origin):
- GB
The HS Aluminium Housed Resistor, in line with MIL 18546 and IEC 115 standards, is designed for exceptional performance with direct heatsink mounting. It offers high power to volume ratio, wound for high pulse capability, and RoHS compliant. With custom designs welcome, this resistor provides various tolerance options and temperature coefficients for versatile applications.
High power to volume ratio for efficient performance
Wound design for high pulse capability
Custom designs welcome for flexibility
Various tolerance options for different precision requirements
Low inductance option available for specific needs
Insulation resistance of 10,000 MΩ minimum
Power dissipation derates linearly up to 200°C for safety
Wide range of ohmic values from R005 to 100K
Surface temperature related to power dissipation for reliability
