Arcol Ohmite HS50 330R F, 330 Ω 50 W Wirewound Wirewound Fixed Resistor ±1 %
- RS Stock No.:
- 285-8226
- Distrelec Article No.:
- 160-32-896
- Mfr. Part No.:
- HS50 330R F
- Brand:
- Arcol Ohmite
Subtotal (1 unit)*
£4.44
(exc. VAT)
£5.33
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 161 unit(s) shipping from 23 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £4.44 |
*price indicative
- RS Stock No.:
- 285-8226
- Distrelec Article No.:
- 160-32-896
- Mfr. Part No.:
- HS50 330R F
- Brand:
- Arcol Ohmite
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Arcol Ohmite | |
| Product Type | Wirewound Fixed Resistor | |
| Resistance | 330Ω | |
| Power Rating | 50W | |
| Series | HS50 | |
| Packaging | Fully Encapsulated | |
| Package/Case | Aluminium | |
| Tolerance | ±1 % | |
| Temperature Coefficient | 100 ppm/°C | |
| Technology | Wirewound | |
| Automotive Standard | No | |
| Overall Length | 72mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 200°C | |
| Standards/Approvals | IEC 115, MIL 18546, RoHS | |
| Overall Width | 29.7mm | |
| Overall Height | 28mm | |
| Overall Diameter | 14.2mm | |
| Select all | ||
|---|---|---|
Brand Arcol Ohmite | ||
Product Type Wirewound Fixed Resistor | ||
Resistance 330Ω | ||
Power Rating 50W | ||
Series HS50 | ||
Packaging Fully Encapsulated | ||
Package/Case Aluminium | ||
Tolerance ±1 % | ||
Temperature Coefficient 100 ppm/°C | ||
Technology Wirewound | ||
Automotive Standard No | ||
Overall Length 72mm | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 200°C | ||
Standards/Approvals IEC 115, MIL 18546, RoHS | ||
Overall Width 29.7mm | ||
Overall Height 28mm | ||
Overall Diameter 14.2mm | ||
- COO (Country of Origin):
- GB
The Aluminium Housed Resistor manufactured in line with the requirements of MIL 18546 and IEC 115, designed for direct heatsink mounting with thermal compound to achieve maximum performance.
High Power to volume
Values from R005 to 100K
Custom designs welcome
RoHS Compliant
