TE Connectivity Barrier Strip, 3 Contact, 10 mm Pitch, 1 Row, 400V, 10A
- RS Stock No.:
- 501-242
- Mfr. Part No.:
- 1776301-8
- Brand:
- TE Connectivity
Subtotal (1 pack of 25 units)*
£160.42
(exc. VAT)
£192.50
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 27 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £160.42 | £6.417 |
*price indicative
- RS Stock No.:
- 501-242
- Mfr. Part No.:
- 1776301-8
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | Barrier Strip | |
| Number of Contacts | 3 | |
| Pitch | 10mm | |
| Current | 10A | |
| Orientation | Right Angle | |
| Contact Material | Brass | |
| Housing Material | Polyamide 6 | |
| Contact Plating | Tin | |
| Number of Rows | 1 | |
| Screw Size | M3 | |
| Wire Size | 22AWG | |
| Voltage | 400V | |
| Series | Europa | |
| Standards/Approvals | UL 94 V-2 | |
| Length | 3mm | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type Barrier Strip | ||
Number of Contacts 3 | ||
Pitch 10mm | ||
Current 10A | ||
Orientation Right Angle | ||
Contact Material Brass | ||
Housing Material Polyamide 6 | ||
Contact Plating Tin | ||
Number of Rows 1 | ||
Screw Size M3 | ||
Wire Size 22AWG | ||
Voltage 400V | ||
Series Europa | ||
Standards/Approvals UL 94 V-2 | ||
Length 3mm | ||
- COO (Country of Origin):
- DE
The TE Connectivity 3 Position Barrier Strip is a preferred solution for wire-to-wire connection needs, expertly designed to facilitate reliable power distribution in various applications. This panel mount component integrates seamlessly into your project, providing a simple yet effective means to connect cables ranging from 22 to 12 AWG. With a compact 10 mm centreline and a durable polyamide housing, it meets the demand for both performance and ease of installation. Ideal for use in environments requiring robust performance, this barrier strip operates at up to 400 V, ensuring a safe and secure connection. Enhanced by tin-plated quick connect tabs and brass contact bases, it stands firm against wear while maintaining excellent conductivity. The thoughtful construction enables straightforward integration into any panel mount configuration, delivering dependable operation every time.
Designed specifically for wire-to-wire configurations
Equipped with zinc chromate plated screws for added durability
Constructed from low halogen materials to meet environmental standards
Features a right-angle orientation for optimised space management
Offers easy handling with 3.1 mm diameter mounting holes for fast installation
Provides substantial contact current ratings for reliable performance
Delivers excellent insulation and safety with UL 94V-2 flammability rating
