SKF 2310 M/C3 50 mm ID 2 Row Self-Aligning Ball Bearing -, 110 mm OD
- RS Stock No.:
- 461-498
- Mfr. Part No.:
- 2310 M/C3
- Brand:
- SKF
Subtotal (1 unit)*
£412.43
(exc. VAT)
£494.92
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £412.43 |
*price indicative
- RS Stock No.:
- 461-498
- Mfr. Part No.:
- 2310 M/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 50 mm | |
| Product Type | Self-Aligning Ball Bearing | |
| Outside Diameter | 110 mm | |
| Race Width | 40mm | |
| Cage Material | Sheet Metal | |
| Ball Material | Bearing Steel | |
| Number of Rows | 2 | |
| Internal Clearance | C3 | |
| Static Load Rating | 20kN | |
| Dynamic Load Rating | 63.7kN | |
| Series | 2310 M/C3 | |
| Bore Type | Cylindrical | |
| Standards/Approvals | RoHS | |
| Limiting Speed | 8500rpm | |
| Bearing Type | Self-aligning Ball Bearing | |
| Flange Outside Diameter | 110mm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 50 mm | ||
Product Type Self-Aligning Ball Bearing | ||
Outside Diameter 110 mm | ||
Race Width 40mm | ||
Cage Material Sheet Metal | ||
Ball Material Bearing Steel | ||
Number of Rows 2 | ||
Internal Clearance C3 | ||
Static Load Rating 20kN | ||
Dynamic Load Rating 63.7kN | ||
Series 2310 M/C3 | ||
Bore Type Cylindrical | ||
Standards/Approvals RoHS | ||
Limiting Speed 8500rpm | ||
Bearing Type Self-aligning Ball Bearing | ||
Flange Outside Diameter 110mm | ||
Rupali
The SKF Self aligning ball bearings have two rows of balls, a common sphered raceway in the outer ring and two deep uninterrupted raceway grooves in the inner ring. They are insensitive to angular misalignment of the shaft relative to the housing, which can be caused, for example, by shaft deflection.
Accommodate static and dynamic misalignment
Excellent high speed performance
Excellent light load performance
Low friction
