SKF 7014 ACDGA/P4A 1 Row Angular Contact Ball Bearing - 70 mm ID, 110 mm OD 20 mm Race Width
- RS Stock No.:
- 461-390
- Mfr. Part No.:
- 7014 ACDGA/P4A
- Brand:
- SKF
Subtotal (1 unit)*
£468.22
(exc. VAT)
£561.86
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 20 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £468.22 |
*price indicative
- RS Stock No.:
- 461-390
- Mfr. Part No.:
- 7014 ACDGA/P4A
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Angular Contact Ball Bearing | |
| Inside Diameter | 70 mm | |
| Outside Diameter | 110 mm | |
| Race Width | 20mm | |
| Ball Material | Steel | |
| Race Material | Steel | |
| End Type | Open | |
| Number of Rows | 1 | |
| Static Load Rating | 44kN | |
| Contact Angle | 25° | |
| Dynamic Load Rating | 48.8kN | |
| Standards/Approvals | RoHS | |
| Series | 7014 | |
| Limiting Speed | 35000, 22000rpm | |
| Race Type | Grooved | |
| Bearing Type | Angular Contact | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Angular Contact Ball Bearing | ||
Inside Diameter 70 mm | ||
Outside Diameter 110 mm | ||
Race Width 20mm | ||
Ball Material Steel | ||
Race Material Steel | ||
End Type Open | ||
Number of Rows 1 | ||
Static Load Rating 44kN | ||
Contact Angle 25° | ||
Dynamic Load Rating 48.8kN | ||
Standards/Approvals RoHS | ||
Series 7014 | ||
Limiting Speed 35000, 22000rpm | ||
Race Type Grooved | ||
Bearing Type Angular Contact | ||
- COO (Country of Origin):
- IT
Zoya
The SKF Single row angular contact ball bearings accommodate radial and axial loads acting simultaneously, where the axial load acts in one direction only. They are designed to accommodate heavy loads at relatively high speeds under low to moderate operating temperatures. Being universally matchable, they can be used together in arrangements to provide effective load sharing, within a predetermined preload range, without the use of shims or similar devices.
Very high running accuracy
Very high load carrying capacity
Relatively high speed and stiffness
Universally matchable
