MPN

Festo Vacuum Generator, 1 mm nozzle, 10 bar 37.7 L/min, VAD series

RS Stock No.:: 711-394
Mfr. Part No.:: VAD-1/4
Brand:: Festo

Festo Vacuum Generator, 1 mm nozzle, 10 bar 37.7 L/min, VAD series

Subtotal (1 unit)*

£91.72

(exc. VAT)

£110.06

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

Plus 25 unit(s) shipping from 10 August 2026
Plus 11 unit(s) shipping from 13 August 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£91.72

*price indicative

RS Stock No.:: 711-394
Mfr. Part No.:: VAD-1/4
Brand:: Festo

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Festo
	Product Type	Vacuum Generator
	Maximum Suction Flow	37.7L/min
	Maximum Vacuum Pressure	10bar
	Nozzle Diameter	1mm
	Series	VAD
	Silencer	No
	Maximum Supply Pressure	10bar
	Supply Port Size	1/4
	Supply Port Type	Threaded
	Vacuum Port Thread Standard	G
	Exhaust Port Thread Standard	G
	Supply Port Thread Standard	G
	Vacuum Port Size	1/4
	Vacuum Port Type	Threaded
	Minimum Operating Temperature	-20°C
	Exhaust Port Type	Threaded
	Maximum Operating Temperature	80°C
	Model Number	9394

	Select all
	Brand Festo
	Product Type Vacuum Generator
	Maximum Suction Flow 37.7L/min
	Maximum Vacuum Pressure 10bar
	Nozzle Diameter 1mm
	Series VAD
	Silencer No
	Maximum Supply Pressure 10bar
	Supply Port Size 1/4
	Supply Port Type Threaded
	Vacuum Port Thread Standard G
	Exhaust Port Thread Standard G
	Supply Port Thread Standard G
	Vacuum Port Size 1/4
	Vacuum Port Type Threaded
	Minimum Operating Temperature -20°C
	Exhaust Port Type Threaded
	Maximum Operating Temperature 80°C
	Model Number 9394

COO (Country of Origin):: IN

Festo VAD Series Vacuum Generator, 10 Bar Maximum Supply Pressure, 37.7 L/min Maximum Suction Flow - VAD-1/4, Numeric Part Number: 9394

This vacuum generator provides pneumatic suction for industrial automation tasks, supplying controlled vacuum from a compressed Air source. It is designed for integration into systems where compact, threaded connections and reliable thermal tolerance are required, operating across a broad temperature range and compatible with standard G‑threaded ports.

Features and Benefits:

• 37.7 L/min maximum suction flow for effective part handling
• 1mm nozzle diameter enables precision vacuum pick‑up
• Threaded 1/4 supply port simplifies secure pneumatic connection
• Threaded 1/4 vacuum port allows standardised system integration
• No silencer fitted to maintain Compact footprint
• Rated to 80°C maximum operating temperature for higher‑heat environments

Applications

• Suitable for pick‑and‑place in electronics assembly lines
• Ideal for handling small components in automation cells
• Used with pneumatic grippers for mechanical part transfer
• Can be used for vacuum clamping in Compact fixtures

What supply pressure range is required for operation?

The unit accepts compressed Air up to 10 bar as its maximum supply pressure for generating vacuum.

What thread standard is used for all ports?

All ports employ G‑threading for compatibility with common pneumatic fittings.

What temperatures can the device withstand during operation?

It is specified for use between -20°C minimum and 80°C maximum operating temperatures.

Is there an integrated exhaust silencer for noise reduction?

No silencer is incorporated, so exhaust noise is unattenuated by the device.
