Infineon 40 V 120 mA Rectifier & Schottky Diode Schottky 3-Pin SOT-143-4-1
- RS Stock No.:
- 249-6978
- Mfr. Part No.:
- BAS4007E6327HTSA1
- Brand:
- Infineon
Bulk discount available
View bulk pricing optionsSubtotal (1 reel of 3000 units)*
£351.00
(exc. VAT)
£420.00
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 18,000 unit(s) shipping from 14 January 2027
- Plus 21,000 unit(s) shipping from 16 June 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 3000 - 3000 | £0.117 | £351.00 |
| 6000 - 12000 | £0.111 | £333.00 |
| 15000 + | £0.104 | £312.00 |
*price indicative
- RS Stock No.:
- 249-6978
- Mfr. Part No.:
- BAS4007E6327HTSA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Product Type | Rectifier & Schottky Diode | |
| Mount Type | Surface | |
| Package Type | SOT-143-4-1 | |
| Maximum Continuous Forward Current If | 120mA | |
| Peak Reverse Repetitive Voltage Vrrm | 40V | |
| Series | BAS40 | |
| Diode Configuration | Parallel Pair | |
| Rectifier Type | Schottky | |
| Pin Count | 3 | |
| Peak Reverse Current Ir | 1μA | |
| Minimum Operating Temperature | -55°C | |
| Peak Non-Repetitive Forward Surge Current Ifsm | 200mA | |
| Maximum Forward Voltage Vf | 1000mV | |
| Maximum Operating Temperature | 150°C | |
| Width | 1mm | |
| Standards/Approvals | RoHS | |
| Length | 2.9mm | |
| Height | 2.4mm | |
| Automotive Standard | AEC-Q101 | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Product Type Rectifier & Schottky Diode | ||
Mount Type Surface | ||
Package Type SOT-143-4-1 | ||
Maximum Continuous Forward Current If 120mA | ||
Peak Reverse Repetitive Voltage Vrrm 40V | ||
Series BAS40 | ||
Diode Configuration Parallel Pair | ||
Rectifier Type Schottky | ||
Pin Count 3 | ||
Peak Reverse Current Ir 1μA | ||
Minimum Operating Temperature -55°C | ||
Peak Non-Repetitive Forward Surge Current Ifsm 200mA | ||
Maximum Forward Voltage Vf 1000mV | ||
Maximum Operating Temperature 150°C | ||
Width 1mm | ||
Standards/Approvals RoHS | ||
Length 2.9mm | ||
Height 2.4mm | ||
Automotive Standard AEC-Q101 | ||
Infineon BAS40 Series Rectifier & Schottky Diode, 120mA Maximum Continuous Forward Current, 40V Peak Reverse Repetitive Voltage - BAS4007E6327HTSA1
This rectifier & schottky diode is a surface-mount dual-diode device designed for low-voltage rectification and fast switching in Compact electronic assemblies. It operates across a wide temperature range suitable for demanding environments and is presented in a small SOT-143-4-1 package for straightforward PCB integration.
Features and Benefits:
• Low forward voltage 1000mV reduces conduction losses
• Max continuous forward current 120mA supports small-signal loads
• Peak reverse repetitive voltage 40V enables moderate-voltage blocking
• Peak non-rep surge current 200mA tolerates transient events
• Peak reverse current 1μA minimises leakage under reverse bias
• Operates from -55°C to 150°C for high-temperature applications
• Max continuous forward current 120mA supports small-signal loads
• Peak reverse repetitive voltage 40V enables moderate-voltage blocking
• Peak non-rep surge current 200mA tolerates transient events
• Peak reverse current 1μA minimises leakage under reverse bias
• Operates from -55°C to 150°C for high-temperature applications
Applications
• Suitable for power management in portable instruments
• Used for input protection in automotive sensing circuits
• Ideal for low-voltage rectification in DC-DC converters
• Can be used for signal demodulation in communication modules
• Used with Compact assemblies where surface mounting is required
• Used for input protection in automotive sensing circuits
• Ideal for low-voltage rectification in DC-DC converters
• Can be used for signal demodulation in communication modules
• Used with Compact assemblies where surface mounting is required
What package facilitates automated assembly?
The device is supplied in a SOT-143-4-1 package compatible with surface-mount placement machines.
How does its diode configuration affect circuit design?
The component is configured as a parallel pair across three pins allowing dual-path rectification or redundancy within constrained footprints.
What environmental standards does it meet for industrial use?
It conforms to RoHS requirements and meets automotive stress specification AEC-Q101 for qualification under vehicle conditions.
How should designers account for surge events?
Designers should consider the 200mA Peak non-repetitive forward surge rating when specifying transient protection and ensure PCB tracks handle brief surges.
