MPN

Infineon 40 V 120 mA Rectifier & Schottky Diode Schottky 3-Pin SOT-23-3 BAS4004E6433HTMA1

RS Stock No.:: 249-6973
Mfr. Part No.:: BAS4004E6433HTMA1
Brand:: Infineon

Infineon 40 V 120 mA Rectifier & Schottky Diode Schottky 3-Pin SOT-23-3 BAS4004E6433HTMA1

Bulk discount available

Subtotal (1 pack of 10 units)*

£1.16

(exc. VAT)

£1.39

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

19,130 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit	Per Pack*
10 - 90	£0.116	£1.16
100 - 490	£0.11	£1.10
500 - 990	£0.105	£1.05
1000 - 2490	£0.101	£1.01
2500 +	£0.081	£0.81

*price indicative

RS Stock No.:: 249-6973
Mfr. Part No.:: BAS4004E6433HTMA1
Brand:: Infineon

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Infineon
	Product Type	Rectifier & Schottky Diode
	Mount Type	Surface
	Package Type	SOT-23-3
	Maximum Continuous Forward Current If	120mA
	Peak Reverse Repetitive Voltage Vrrm	40V
	Diode Configuration	Series
	Series	BAS40
	Rectifier Type	Schottky
	Pin Count	3
	Peak Reverse Current Ir	1μA
	Peak Non-Repetitive Forward Surge Current Ifsm	200mA
	Maximum Forward Voltage Vf	1000mV
	Minimum Operating Temperature	-55°C
	Maximum Operating Temperature	150°C
	Height	2.4mm
	Standards/Approvals	RoHS
	Length	2.9mm
	Width	1 mm
	Automotive Standard	AEC-Q101

	Select all
	Brand Infineon
	Product Type Rectifier & Schottky Diode
	Mount Type Surface
	Package Type SOT-23-3
	Maximum Continuous Forward Current If 120mA
	Peak Reverse Repetitive Voltage Vrrm 40V
	Diode Configuration Series
	Series BAS40
	Rectifier Type Schottky
	Pin Count 3
	Peak Reverse Current Ir 1μA
	Peak Non-Repetitive Forward Surge Current Ifsm 200mA
	Maximum Forward Voltage Vf 1000mV
	Minimum Operating Temperature -55°C
	Maximum Operating Temperature 150°C
	Height 2.4mm
	Standards/Approvals RoHS
	Length 2.9mm
	Width 1 mm
	Automotive Standard AEC-Q101
