Finder PCB Mount Power Relay, 230V ac Coil, 16A Switching Current, SPDT

RS Stock No.:: 894-9436
Mfr. Part No.:: 41.61.8.230.0000
Brand:: Finder

Finder PCB Mount Power Relay, 230V ac Coil, 16A Switching Current, SPDT

Bulk discount available

Subtotal (1 unit)*

£12.13

(exc. VAT)

£14.56

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

6 unit(s) ready to ship
Plus 52 unit(s) ready to ship from another location

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 - 4	£12.13
5 - 9	£11.53
10 +	£11.15

*price indicative

RS Stock No.:: 894-9436
Mfr. Part No.:: 41.61.8.230.0000
Brand:: Finder

41 Series - 41.52, 41.31 & 41.61

PCB mount power relays with ac and dc coils.

Low profile
Flux proof, RTII
Minimum switching load 300mW
8mm creepage and clearance between coil and contacts
Dimensions 15.7x12.5x29 mm

Approvals

UL (Canada & US); VDE

Finder 41 Series Power Relay, 230V AC Coil Voltage, 16A Switching Current - 41.61.8.230.0000

This power relay is a low-profile SPDT relay designed for PCB mounting. Operating at a robust 230V AC, this device features a compact design measuring 29 x 12.6 x 15.7mm, ideal for tight spaces in automation and control systems. With a maximum switching current of 16A, it meets diverse application requirements while ensuring reliability and efficiency.

Features & Benefits

• Designed for PCB mounting, offering versatility in applications
• Robust current capacity of 16A for various demands
• High voltage relay with isolation up to 6kV for safety
• Incorporates silver alloy relay contacts for enhanced performance
• Complies with cULus standards for certified reliability
• Compact dimensions support space-saving designs

Applications

• Utilised in building automation systems for efficient control
• Ideal for timers and lighting controls in residential and commercial settings
• Commonly found in electronic circuit boards for reliable operation
• Employed in vending machines to ensure robust functionality
• Suitable for control systems in industrial environments

How does the design of this relay enhance safety in high-voltage applications?

The relay's isolation rating of 6kV between coil and contacts provides significant protection against electrical surges, ensuring safe operation in high-voltage environments.

What type of contact material is utilised, and what advantages does it provide?

The relay uses silver alloy for its contacts, which offers enhanced conductivity and durability, reducing wear over time and improving longevity in various applications.

Can this relay accommodate both AC and DC loads?

Yes, it can handle a maximum switching voltage of 400V AC and 110V DC, making it suitable for a wide range of loads in diverse electrical setups.

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Finder
	Coil Voltage	230V ac
	Contact Configuration	SPDT
	Mounting Type	PCB Mount
	Switching Current	16A
	Number of Poles	1
	Series	41 Series
	Terminal Type	PCB Pin
	Maximum Switching Voltage AC	400V ac
	Maximum Switching Voltage DC	110V dc
	Maximum Switching Current AC	30 A
	Length	29mm
	Coil Power	400mW
	Maximum Operating Temperature	+70°C
	Depth	12.6mm
	Minimum Operating Temperature	-40°C
	Isolation Coil To Contact	6kV
	Contact Material	Silver Alloy
	Height	15.7mm
	Life	50000 Cycles
	Standards Met	cULus, EAC, PCT, RINA, UL, VDE
	Dimensions	29 x 12.6 x 15.7mm

	Select all
	Brand Finder
	Coil Voltage 230V ac
	Contact Configuration SPDT
	Mounting Type PCB Mount
	Switching Current 16A
	Number of Poles 1
	Series 41 Series
	Terminal Type PCB Pin
	Maximum Switching Voltage AC 400V ac
	Maximum Switching Voltage DC 110V dc
	Maximum Switching Current AC 30 A
	Length 29mm
	Coil Power 400mW
	Maximum Operating Temperature +70°C
	Depth 12.6mm
	Minimum Operating Temperature -40°C
	Isolation Coil To Contact 6kV
	Contact Material Silver Alloy
	Height 15.7mm
	Life 50000 Cycles
	Standards Met cULus, EAC, PCT, RINA, UL, VDE
	Dimensions 29 x 12.6 x 15.7mm
