Hongfa Europe GMBH PCB Mount Power Relay, 5V dc Coil, 30A Switching Current, SPST
- RS Stock No.:
- 176-2902
- Mfr. Part No.:
- HF165FD/5-HY1TF
- Brand:
- Hongfa Europe GMBH
Bulk discount available
Subtotal (1 pack of 2 units)*
£4.38
(exc. VAT)
£5.26
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 88 unit(s) ready to ship
- Plus 44 left, ready to ship from another location
- Plus 30 unit(s) shipping from 08 September 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
2 - 98 | £2.19 | £4.38 |
100 - 298 | £1.955 | £3.91 |
300 - 498 | £1.85 | £3.70 |
500 + | £1.68 | £3.36 |
*price indicative
- RS Stock No.:
- 176-2902
- Mfr. Part No.:
- HF165FD/5-HY1TF
- Brand:
- Hongfa Europe GMBH
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Hongfa Europe GMBH | |
Coil Voltage | 5V dc | |
Contact Configuration | SPST | |
Mounting Type | PCB Mount | |
Switching Current | 30A | |
Number of Poles | 1 | |
Latching | No | |
Terminal Type | PCB Pin | |
Maximum Switching Voltage AC | 277V | |
Maximum Switching Current DC | 30 A | |
Maximum Switching Current AC | 30 A | |
Length | 32.2mm | |
Coil Resistance | 27Ω | |
Coil Power | 900mW | |
Series | HF165FD | |
Height | 20.4mm | |
Minimum Operating Temperature | -40°C | |
Maximum Operating Temperature | +85°C | |
Isolation Coil To Contact | 6kV | |
Life | 1 x 10^7 cycles | |
Contact Material | Silver Alloy | |
Depth | 27.5mm | |
Maximum Switching Power AC | 8.31 kVA | |
Select all | ||
---|---|---|
Brand Hongfa Europe GMBH | ||
Coil Voltage 5V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 30A | ||
Number of Poles 1 | ||
Latching No | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 277V | ||
Maximum Switching Current DC 30 A | ||
Maximum Switching Current AC 30 A | ||
Length 32.2mm | ||
Coil Resistance 27Ω | ||
Coil Power 900mW | ||
Series HF165FD | ||
Height 20.4mm | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +85°C | ||
Isolation Coil To Contact 6kV | ||
Life 1 x 10^7 cycles | ||
Contact Material Silver Alloy | ||
Depth 27.5mm | ||
Maximum Switching Power AC 8.31 kVA | ||
