TE Connectivity AMPMODU HV-100/HV-190 Series Right Angle Board PCB Header, 8 Contact(s), 2.54 mm Pitch, 2 Row, Shrouded
- RS Stock No.:
- 277-7208
- Distrelec Article No.:
- 143-84-061
- Mfr. Part No.:
- 216604-8
- Brand:
- TE Connectivity
Bulk discount available
Subtotal (1 box of 105 units)*
£378.42
(exc. VAT)
£454.125
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 03 June 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 105 - 105 | £3.604 | £378.42 |
| 210 + | £3.326 | £349.23 |
*price indicative
- RS Stock No.:
- 277-7208
- Distrelec Article No.:
- 143-84-061
- Mfr. Part No.:
- 216604-8
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | AMPMODU HV-100/HV-190 | |
| Product Type | PCB Header | |
| Pitch | 2.54mm | |
| Current | 3A | |
| Number of Contacts | 8 | |
| Housing Material | Polyester | |
| Number of Rows | 2 | |
| Orientation | Right Angle | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | Board-to-Board | |
| Mount Type | Board | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold | |
| Minimum Operating Temperature | -65°C | |
| Termination Type | PCB | |
| Row Pitch | 2.54mm | |
| Maximum Operating Temperature | 125°C | |
| Tail Pin Length | 3.2mm | |
| Standards/Approvals | REACH, RoHS, UL 94 V-0 | |
| Mating Pin Length | 3.2mm | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series AMPMODU HV-100/HV-190 | ||
Product Type PCB Header | ||
Pitch 2.54mm | ||
Current 3A | ||
Number of Contacts 8 | ||
Housing Material Polyester | ||
Number of Rows 2 | ||
Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Connector System Board-to-Board | ||
Mount Type Board | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold | ||
Minimum Operating Temperature -65°C | ||
Termination Type PCB | ||
Row Pitch 2.54mm | ||
Maximum Operating Temperature 125°C | ||
Tail Pin Length 3.2mm | ||
Standards/Approvals REACH, RoHS, UL 94 V-0 | ||
Mating Pin Length 3.2mm | ||
The TE Connectivity PCB Mount Receptacle has Board-to-Board connector system used for centreline interconnection system.
Standard connector profile
Right angle PCB mount orientation
