TE Connectivity AMPMODU Series Vertical Board PCB Header, 3 Contact(s), 2.54 mm Pitch, 1 Row(s), Unshrouded

View all PCB Headers

Subtotal (1 pack of 540 units)*

£243.94

(exc. VAT)

£292.73

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£243.94£0.452

*price indicative

RS Stock No.:
505-900
Mfr. Part No.:
5-146280-3
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Product Type

PCB Header

Series

AMPMODU

Current

3A

Pitch

2.54mm

Housing Material

Copper Alloy

Number of Contacts

3

Number of Rows

1

Orientation

Vertical

Shrouded/Unshrouded

Unshrouded

Connector System

Board-to-Board

Mount Type

Board

Contact Material

Copper Alloy

Contact Plating

Gold

Termination Type

Solder

Minimum Operating Temperature

65°C

Row Pitch

2.54mm

Tail Pin Length

3.05mm

Maximum Operating Temperature

105°C

Standards/Approvals

CSA LR7189, UL 94V-0, UL E28476

COO (Country of Origin):
MX
The TE Connectivity PCB Mount Header is meticulously designed for vertical board-to-board connections, providing a reliable interface for your electronic assemblies. With a focus on durability and performance, it features three positions and a 2.54 mm centreline, making it ideal for a variety of applications. The header is characterised by its breakaway design, allowing for flexible configurations. Enhanced with gold plating and a robust through-hole solder termination method, it ensures superior conductivity and longevity. Crafted from high-quality LCP materials, this connector not only meets demanding operational criteria but also excels in environments with high temperature variations. This product is a staple for those seeking optimal performance in electronic connectors.

Vertical orientation facilitates efficient space utilisation on the PCB

Breakaway design allows for customisable configuration and easy integration

Gold-plated contacts enhance electrical conductivity

Suitable for fully loaded contact conditions ensuring dependable operational performance

Constructed to operate effectively across a wide temperature range from -65 to 105 °C

Compatible with industry standards, ensuring quality and reliability

Supports through-hole solder termination for secure mounting

Primary product colour of black integrates seamlessly with most PCB designs

Low bromine/chlorine content contributes to a safer environmental footprint

Pin-in-paste capability allows for a straightforward manufacturing process
