TE Connectivity AMPMODU Series Right Angle Board Mount PCB Header, 3 Contact(s), 2.54mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 472-063
- Mfr. Part No.:
- 5-102523-2
- Brand:
- TE Connectivity
Subtotal (1 tube of 150 units)*
£198.22
(exc. VAT)
£237.86
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
---|---|---|
1 + | £198.22 | £1.321 |
*price indicative
- RS Stock No.:
- 472-063
- Mfr. Part No.:
- 5-102523-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TE Connectivity | |
Series | AMPMODU | |
Pitch | 2.54mm | |
Number of Contacts | 3 | |
Number of Rows | 1 | |
Body Orientation | Right Angle | |
Shrouded/Unshrouded | Shrouded | |
Mounting Type | Board Mount | |
Select all | ||
---|---|---|
Brand TE Connectivity | ||
Series AMPMODU | ||
Pitch 2.54mm | ||
Number of Contacts 3 | ||
Number of Rows 1 | ||
Body Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mounting Type Board Mount | ||
- COO (Country of Origin):
- MX
The TE Connectivity PCB Mount Header is a versatile and robust interconnection solution designed for seamless right-angle board-to-board applications. Featuring a compact 3-position configuration with a 2.54 mm centreline, this fully shrouded header is engineered for reliability and performance. It is crafted from high-quality thermoplastic, ensuring durability in a variety of operating environments. The effective shielding provided by its design enhances signal integrity, making it an ideal choice for applications where dependable connectivity is crucial. This connector is not only compliant with rigorous industry standards but also boasts a broad operational temperature range, making it suitable for both consumer and industrial electronics. With its user-friendly termination method and outstanding insulation resistance, this header simplifies installation and ensures secure connections over time.
Easy integration into existing PCB layouts
Polarization ensures correct mating alignment
Robust contact underplating material enhances electrical reliability
Compact design saves space on densely packed boards
Wave solder capable for efficient assembly processes
High insulation resistance guarantees performance integrity
Black housing colour provides a professional appearance
Meets stringent UL flammability ratings for safety
Polarization ensures correct mating alignment
Robust contact underplating material enhances electrical reliability
Compact design saves space on densely packed boards
Wave solder capable for efficient assembly processes
High insulation resistance guarantees performance integrity
Black housing colour provides a professional appearance
Meets stringent UL flammability ratings for safety
