TE Connectivity 1-216604-0 Series Right Angle PCB PCB Header, 10 Contact(s), 2.54 mm Pitch, 2 Row
- RS Stock No.:
- 470-176
- Distrelec Article No.:
- 304-53-439
- Mfr. Part No.:
- 1-216604-0
- Brand:
- TE Connectivity
Subtotal (1 pack of 50 units)*
£164.36
(exc. VAT)
£197.23
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £164.36 | £3.287 |
*price indicative
- RS Stock No.:
- 470-176
- Distrelec Article No.:
- 304-53-439
- Mfr. Part No.:
- 1-216604-0
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | 1-216604-0 | |
| Product Type | PCB Header | |
| Pitch | 2.54mm | |
| Current | 3A | |
| Number of Contacts | 10 | |
| Housing Material | Fibreglass Polyester | |
| Number of Rows | 2 | |
| Orientation | Right Angle | |
| Connector System | Board-to-Board | |
| Mount Type | PCB | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold | |
| Minimum Operating Temperature | 65°C | |
| Termination Type | Solder | |
| Row Pitch | 2.54mm | |
| Maximum Operating Temperature | 125°C | |
| Tail Pin Length | 3.2mm | |
| Standards/Approvals | UL 94 V-0 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series 1-216604-0 | ||
Product Type PCB Header | ||
Pitch 2.54mm | ||
Current 3A | ||
Number of Contacts 10 | ||
Housing Material Fibreglass Polyester | ||
Number of Rows 2 | ||
Orientation Right Angle | ||
Connector System Board-to-Board | ||
Mount Type PCB | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold | ||
Minimum Operating Temperature 65°C | ||
Termination Type Solder | ||
Row Pitch 2.54mm | ||
Maximum Operating Temperature 125°C | ||
Tail Pin Length 3.2mm | ||
Standards/Approvals UL 94 V-0 | ||
- COO (Country of Origin):
- PL
The TE Connectivity Mount Receptacle is a highly versatile connector designed for right-angle board-to-board applications. With a 10-position layout, it ensures efficient space utilisation while maintaining strong signal integrity. The connector features a robust design suitable for various electronic assemblies, making it ideal for high-density configurations. Crafted for durability, the receptacle supports through-hole soldering, enhancing its reliability in demanding environments. The gold-plated contact finish not only offers excellent conductivity but also prevents corrosion, ensuring optimal performance over time.
Robust construction designed for durability in high-density applications
Gold plating on contacts enhances conductivity and resists oxidation
Right-angle orientation allows for optimal PCB layout space management
Mating square post dimensions ensure secure connections
Closed entry housing provides protection for mating contacts
PCB mount alignment features help streamline assembly processes
Suitable for use in varied operating temperatures, enhancing versatility
Wave solder capability ensures compatibility with modern manufacturing techniques
