TE Connectivity Economy Power Series Vertical PCB PCB Header, 7 Contact(s), 3.96 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 469-057
- Mfr. Part No.:
- 2-1123723-7
- Brand:
- TE Connectivity
Subtotal (1 pack of 800 units)*
£216.72
(exc. VAT)
£260.06
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £216.72 | £0.271 |
*price indicative
- RS Stock No.:
- 469-057
- Mfr. Part No.:
- 2-1123723-7
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Header | |
| Series | Economy Power | |
| Current | 7.5A | |
| Pitch | 3.96mm | |
| Number of Contacts | 7 | |
| Housing Material | Fibreglass Reinforced Polybutylene Terephthalate | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | Wire-to-Board | |
| Mount Type | PCB | |
| Contact Material | Brass | |
| Contact Plating | Tin Plated | |
| Minimum Operating Temperature | 30°C | |
| Row Pitch | 3.96mm | |
| Termination Type | Solder | |
| Contact Gender | Male | |
| Tail Pin Length | 3.7mm | |
| Maximum Operating Temperature | 105°C | |
| Mating Pin Length | 7.7mm | |
| Standards/Approvals | 2016 Compliant, China RoHS 2 Directive MIIT Order No 32, EU ELV Directive 2000/53/EC Compliant, EU RoHS Directive 2011/65/EU Compliant, UL 94HB | |
| Voltage | 250 V | |
| Distrelec Product Id | 304-53-748 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Header | ||
Series Economy Power | ||
Current 7.5A | ||
Pitch 3.96mm | ||
Number of Contacts 7 | ||
Housing Material Fibreglass Reinforced Polybutylene Terephthalate | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Connector System Wire-to-Board | ||
Mount Type PCB | ||
Contact Material Brass | ||
Contact Plating Tin Plated | ||
Minimum Operating Temperature 30°C | ||
Row Pitch 3.96mm | ||
Termination Type Solder | ||
Contact Gender Male | ||
Tail Pin Length 3.7mm | ||
Maximum Operating Temperature 105°C | ||
Mating Pin Length 7.7mm | ||
Standards/Approvals 2016 Compliant, China RoHS 2 Directive MIIT Order No 32, EU ELV Directive 2000/53/EC Compliant, EU RoHS Directive 2011/65/EU Compliant, UL 94HB | ||
Voltage 250 V | ||
Distrelec Product Id 304-53-748 | ||
- COO (Country of Origin):
- US
The TE Connectivity PCB Mount Header is a versatile and efficient solution for wire-to-board connectivity within electronic applications. Designed to accommodate seven positions, this vertical connector is engineered for optimal electrical performance and reliability. Crafted with a partially shrouded design, it ensures secure and accurate connections, making it ideal for power circuit applications. With a centreline pitch of 3.96 mm, it facilitates easy integration into compact electronic devices while maintaining robustness. This connector is suitable for various operational environments, boasting an impressive temperature range of -30 to 105 °C, which adds to its versatility. Furthermore, the connector features a low profile for space-conscious designs, making it an excellent choice for contemporary electronic assemblies.
Designed for wire-to-board applications, ensuring high-quality connections
Offers a low connector profile for space-saving designs
Constructed with durable materials to withstand harsh operating conditions
Provides easy mating retention through a latching mechanism
Equipped with straightforward pin contact layout for enhanced performance
Designed to be wave solder capable, facilitating efficient manufacturing processes
Features a robust housing material that ensures longevity and performance stability
Compliant with EU RoHS and ELV directives, promoting environmentally-conscious use
