TE Connectivity Micro MATE-N-LOK Series Vertical Board PCB Header, 5 Contact(s), 3 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 467-645
- Distrelec Article No.:
- 304-50-440
- Mfr. Part No.:
- 2-1445051-5
- Brand:
- TE Connectivity
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 467-645
- Distrelec Article No.:
- 304-50-440
- Mfr. Part No.:
- 2-1445051-5
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Header | |
| Series | Micro MATE-N-LOK | |
| Pitch | 3mm | |
| Current | 5A | |
| Number of Contacts | 5 | |
| Housing Material | Nylon | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Board | |
| Connector System | Wire-to-Board | |
| Contact Material | Contact Base Material Brass | |
| Contact Plating | Tin Plated | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | Solder | |
| Row Pitch | 3mm | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 3.18mm | |
| Mating Pin Length | 4.15mm | |
| Standards/Approvals | CNR, UL 94V-0, UL E28476, USR | |
| Voltage | 250V | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Header | ||
Series Micro MATE-N-LOK | ||
Pitch 3mm | ||
Current 5A | ||
Number of Contacts 5 | ||
Housing Material Nylon | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Board | ||
Connector System Wire-to-Board | ||
Contact Material Contact Base Material Brass | ||
Contact Plating Tin Plated | ||
Minimum Operating Temperature -40°C | ||
Termination Type Solder | ||
Row Pitch 3mm | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 3.18mm | ||
Mating Pin Length 4.15mm | ||
Standards/Approvals CNR, UL 94V-0, UL E28476, USR | ||
Voltage 250V | ||
- COO (Country of Origin):
- CN
The TE Connectivity PCB Mount Header, designed for vertical wire-to-board applications, is ideal for connecting 5-position setups with a compact 3 mm centreline spacing. Its fully shrouded construction ensures secure connectivity and alignment, making it a staple in designs where reliability is paramount. Finished with a high-quality tin plating over a durable phosphor bronze material, this connector not only facilitates efficient electrical transmission but also withstands harsh environmental conditions with an impressive temperature range. With ease of installation through through-hole soldering, this component guarantees superb mounting robustness on printed circuit boards, providing engineers with a versatile solution for a range of applications in various industrial settings.
Streamlined design enables easy integration into compact spaces
Fully shrouded header structure enhances connector stability
Robust high-temperature nylon housing supports durability
Locking tab mechanism ensures consistent mating retention
Nickel underplating offers excellent corrosion resistance
Low halogen materials contribute to environmentally friendly design
Packaged conveniently in trays to facilitate easy handling
Power applications suited with fully loaded contact capabilities
Polarisation features aid in correct alignment during assembly
