STMicroelectronics SCT Type N-Channel MOSFET, 56 A, 1200 V Enhancement, 3-Pin Hip-247 SCT025W120G3AG
- RS Stock No.:
- 215-071
- Mfr. Part No.:
- SCT025W120G3AG
- Brand:
- STMicroelectronics
Subtotal (1 tube of 30 units)*
£678.48
(exc. VAT)
£814.17
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 30 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
|---|---|---|
| 30 + | £22.616 | £678.48 |
*price indicative
- RS Stock No.:
- 215-071
- Mfr. Part No.:
- SCT025W120G3AG
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Channel Type | Type N | |
| Product Type | MOSFET | |
| Maximum Continuous Drain Current Id | 56A | |
| Maximum Drain Source Voltage Vds | 1200V | |
| Package Type | Hip-247 | |
| Series | SCT | |
| Mount Type | Through Hole | |
| Pin Count | 3 | |
| Maximum Drain Source Resistance Rds | 27mΩ | |
| Channel Mode | Enhancement | |
| Maximum Gate Source Voltage Vgs | 22 V | |
| Minimum Operating Temperature | -55°C | |
| Maximum Power Dissipation Pd | 388W | |
| Typical Gate Charge Qg @ Vgs | 73nC | |
| Maximum Operating Temperature | 200°C | |
| Standards/Approvals | RoHS | |
| Width | 15.6 mm | |
| Length | 34.8mm | |
| Height | 5mm | |
| Automotive Standard | AEC-Q101 | |
| Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Channel Type Type N | ||
Product Type MOSFET | ||
Maximum Continuous Drain Current Id 56A | ||
Maximum Drain Source Voltage Vds 1200V | ||
Package Type Hip-247 | ||
Series SCT | ||
Mount Type Through Hole | ||
Pin Count 3 | ||
Maximum Drain Source Resistance Rds 27mΩ | ||
Channel Mode Enhancement | ||
Maximum Gate Source Voltage Vgs 22 V | ||
Minimum Operating Temperature -55°C | ||
Maximum Power Dissipation Pd 388W | ||
Typical Gate Charge Qg @ Vgs 73nC | ||
Maximum Operating Temperature 200°C | ||
Standards/Approvals RoHS | ||
Width 15.6 mm | ||
Length 34.8mm | ||
Height 5mm | ||
Automotive Standard AEC-Q101 | ||
The STMicroelectronics Silicon carbide Power MOSFET device has been developed using ST’s Advanced and innovative 3rd generation SiC MOSFET technology. The device features a very low RDS(on) over the entire temperature range combined with low capacitances and very high switching operations, which improve application performance in frequency, energy efficiency, system size and weight reduction.
High speed switching performances
Very fast and robust intrinsic body diode
