PUI Audio 1 W Miniature Speaker, 25 mm Lead Length
- RS Stock No.:
- 276-745
- Mfr. Part No.:
- AS01808AO-WP-R
- Brand:
- PUI Audio
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£2.46
(exc. VAT)
£2.95
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 46 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £2.46 |
| 10 - 99 | £2.22 |
| 100 - 499 | £2.04 |
| 500 - 999 | £1.89 |
| 1000 + | £1.53 |
*price indicative
- RS Stock No.:
- 276-745
- Mfr. Part No.:
- AS01808AO-WP-R
- Brand:
- PUI Audio
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | PUI Audio | |
| Product Type | Miniature Speaker | |
| Sound Level | 94dBA | |
| Tone Type | Continuous | |
| Rated Power | 1W | |
| Lead Length | 25mm | |
| Cone Material | Mylar | |
| Impedance | 8Ω | |
| Standards/Approvals | RoHS 2011/65/EU, IP65 | |
| Select all | ||
|---|---|---|
Brand PUI Audio | ||
Product Type Miniature Speaker | ||
Sound Level 94dBA | ||
Tone Type Continuous | ||
Rated Power 1W | ||
Lead Length 25mm | ||
Cone Material Mylar | ||
Impedance 8Ω | ||
Standards/Approvals RoHS 2011/65/EU, IP65 | ||
- COO (Country of Origin):
- CN
PUI Audio Miniature Speaker, 1W Rated Power, 8Ω Impedance - AS01808AO-WP-R
This miniature speaker provides Compact acoustic signalling for electronic and automation equipment, delivering high-frequency audio in confined assemblies. It is designed as a small sound-emitting component for integration into control panels, instruments and Compact enclosures where a continuous audio tone is required and environmental protection is necessary.
Features and Benefits:
• 8Ω impedance delivers predictable load matching for drivers
• 1W rated power supports clear audible alerts at low power
• 14kHz frequency produces distinct high-frequency tones
• 94dBA sensitivity yields strong output from minimal drive
• IP65 protection allows use in dusty or water‑splashed locations
• Aluminium cone gives stable high-frequency response
• 1W rated power supports clear audible alerts at low power
• 14kHz frequency produces distinct high-frequency tones
• 94dBA sensitivity yields strong output from minimal drive
• IP65 protection allows use in dusty or water‑splashed locations
• Aluminium cone gives stable high-frequency response
Applications
• Suitable for status alerts in industrial control panels
• Ideal for audible warnings in automation systems
• Used with handheld test instruments requiring tone indication
• Can be used for machine fault notification in manufacturing
• Ideal for audible warnings in automation systems
• Used with handheld test instruments requiring tone indication
• Can be used for machine fault notification in manufacturing
What electrical connection is provided for installation?
Two leads are fitted with a 25mm length to simplify soldering or Terminal attachment during assembly.
How thin can the component be accommodated in tight enclosures?
The speaker has a 2.5mm overall height allowing placement behind slim bezels or within shallow cavities.
What footprint should be allowed on a mounting surface?
The body dimensions are 18mm by 13mm so a Compact cut-out or mounting zone matching those dimensions is sufficient.
Which tone behaviour should be expected when driven continuously?
It is specified to produce a continuous tone output suitable for sustained audible signalling without intermittent modulation.
