PUI Audio 1 W Miniature Speaker 18 mm Dia., 152 mm Lead Length 5 mm
- RS Stock No.:
- 276-747
- Mfr. Part No.:
- AS01808MR-LW152-R
- Brand:
- PUI Audio
Get a bulk buy discount
Add 10 more to save 10%
View bulk pricing optionsSubtotal (1 unit)*
£3.18
(exc. VAT)
£3.82
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 50 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Saving |
|---|---|---|
| 1 - 9 | £3.18 | - |
| 10 - 99 | £2.86 | 10% |
| 100 - 499 | £2.64 | 16% |
| 500 - 999 | £2.45 | 22% |
| 1000 + | £1.99 | 37% |
*price indicative
- RS Stock No.:
- 276-747
- Mfr. Part No.:
- AS01808MR-LW152-R
- Brand:
- PUI Audio
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | PUI Audio | |
| Product Type | Miniature Speaker | |
| Sound Level | 80dBA | |
| Rated Power | 1W | |
| Lead Length | 152mm | |
| Cone Material | Mylar | |
| Frequency | 18000Hz | |
| Impedance | 8Ω | |
| Diameter | 18mm | |
| Height | 5mm | |
| Standards/Approvals | RoHS 2015/863/EU, REACH | |
| Length | 18mm | |
| Select all | ||
|---|---|---|
Brand PUI Audio | ||
Product Type Miniature Speaker | ||
Sound Level 80dBA | ||
Rated Power 1W | ||
Lead Length 152mm | ||
Cone Material Mylar | ||
Frequency 18000Hz | ||
Impedance 8Ω | ||
Diameter 18mm | ||
Height 5mm | ||
Standards/Approvals RoHS 2015/863/EU, REACH | ||
Length 18mm | ||
- COO (Country of Origin):
- CN
The PUI Audio Speaker is round and operates within a temperature range of 25° to 60°, has an impedance of 8 ohms, a resonant frequency of 0.65 kHz, a sound pressure level of 80 dB, a rated input power of 1 watt, and is classified as standard temperature grade.
Diaphragm material is Mylar
Magnet material is Ndfeb
Tolerance is 3 dB
