TE Connectivity, 5102159, 5102159-9 2.54mm Pitch 40 Way Right Angle FPC Connector
- RS Stock No.:
- 481-059
- Mfr. Part No.:
- 5102159-9
- Brand:
- TE Connectivity
Subtotal (1 tray of 50 units)*
£146.60
(exc. VAT)
£175.92
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 999,999,999 unit(s) shipping from 10 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tray(s) | Per Tray | Per unit* |
---|---|---|
1 + | £146.60 | £2.932 |
*price indicative
- RS Stock No.:
- 481-059
- Mfr. Part No.:
- 5102159-9
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TE Connectivity | |
Number of Contacts | 40 | |
Contact Material | Phosphor Bronze | |
Pitch | 2.54mm | |
Mounting Type | Board Mount | |
Body Orientation | Right Angle | |
Series | 5102159 | |
Series Number | 5102159-9 | |
Select all | ||
---|---|---|
Brand TE Connectivity | ||
Number of Contacts 40 | ||
Contact Material Phosphor Bronze | ||
Pitch 2.54mm | ||
Mounting Type Board Mount | ||
Body Orientation Right Angle | ||
Series 5102159 | ||
Series Number 5102159-9 | ||
- COO (Country of Origin):
- CN
The TE Connectivity wire-to-board connector stands out in the market for its exceptional design, engineered specifically for seamless integration in various electronic applications. The product features a 40-position configuration, optimised for signal transmission, and is suitable for use in demanding environments with an impressive operating temperature range of -65 to 105 °C. Highlighting a right-angle PCB mount orientation, this connector ensures efficient space utilisation and simplified board layout. Its robust construction includes a nylon housing that provides excellent durability, while the gold flash plating ensures superior conductivity and reliability. With wave solder capability up to 265 °C, this connector is designed for high-performance applications, making it an ideal choice for modern electronic connectivity needs.
Optimised for easy assembly on printed circuit boards
Dual polarising design enhances mating accuracy and reliability
Ejection latch mechanism provides secure mating retention
Insulation resistance of 5000 MΩ ensures dependable performance
Compatible with a variety of ribbon cable connectors for versatility
Mating alignment feature enhances installation precision
Trays are used for organised and efficient packaging
Supports high voltage ratings to cater to various applications
Integrated nickel underplating promotes durability and longevity
Ideal for both consumer and industrial electronic devices
Dual polarising design enhances mating accuracy and reliability
Ejection latch mechanism provides secure mating retention
Insulation resistance of 5000 MΩ ensures dependable performance
Compatible with a variety of ribbon cable connectors for versatility
Mating alignment feature enhances installation precision
Trays are used for organised and efficient packaging
Supports high voltage ratings to cater to various applications
Integrated nickel underplating promotes durability and longevity
Ideal for both consumer and industrial electronic devices
