TE Connectivity, 1-5499345-2 2.54 mm Pitch 64 Way Right Angle FPC Connector, Solder
- RS Stock No.:
- 470-072
- Distrelec Article No.:
- 304-48-400
- Mfr. Part No.:
- 1-5499345-2
- Brand:
- TE Connectivity
Subtotal (1 pack of 24 units)*
£202.65
(exc. VAT)
£243.18
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 19 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £202.65 | £8.444 |
*price indicative
- RS Stock No.:
- 470-072
- Distrelec Article No.:
- 304-48-400
- Mfr. Part No.:
- 1-5499345-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Number of Contacts | 64 | |
| Product Type | FPC Connector | |
| Contact Material | Brass | |
| Current | 1A | |
| Pitch | 2.54mm | |
| Mount Type | PCB | |
| Contact Position | Pin | |
| Termination Type | Solder | |
| Orientation | Right Angle | |
| Locking Mechanism | Yes | |
| Voltage | 250V | |
| Series | 1-5499345-2 | |
| Minimum Operating Temperature | 65°C | |
| Maximum Operating Temperature | 105°C | |
| Number of Rows | 2 | |
| Standards/Approvals | 2016, China RoHS 2 Directive MIIT Order No 32, EU ELV Directive 2000/53/EC, EU REACH Regulation (EC) No. 1907/2006, EU RoHS Directive 2011/65/EU, UL 94V-0 | |
| Housing Material | Glass Filled Nylon/Polyester | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Number of Contacts 64 | ||
Product Type FPC Connector | ||
Contact Material Brass | ||
Current 1A | ||
Pitch 2.54mm | ||
Mount Type PCB | ||
Contact Position Pin | ||
Termination Type Solder | ||
Orientation Right Angle | ||
Locking Mechanism Yes | ||
Voltage 250V | ||
Series 1-5499345-2 | ||
Minimum Operating Temperature 65°C | ||
Maximum Operating Temperature 105°C | ||
Number of Rows 2 | ||
Standards/Approvals 2016, China RoHS 2 Directive MIIT Order No 32, EU ELV Directive 2000/53/EC, EU REACH Regulation (EC) No. 1907/2006, EU RoHS Directive 2011/65/EU, UL 94V-0 | ||
Housing Material Glass Filled Nylon/Polyester | ||
- COO (Country of Origin):
- CN
The TE Connectivity Universal Header is designed specifically for ribbon cable connections, ensuring reliable board-to-board communication with 64 positions. Engineered with meticulous attention to detail, it features a right angle orientation and a minimal 2.54 mm centreline for efficient use of space. Its robust construction allows for through-hole soldering, providing a sturdy connection that withstands the rigours of electronic applications. The header's thermoplastic material, infused with glass fill for enhanced durability, coupled with its standard connector profile, makes it suitable for a wide range of environments. Offering low maintenance and ease of use, this connector is compliant with EU directives, ensuring it meets necessary safety and environmental standards. The AMP-LATCH design guarantees secure mating retention, making it an ideal choice for applications requiring dependable connections.
Designed for reliable board-to-board connections in various electronic applications
Right angle orientation optimises space utilisation on printed circuit boards
Utilises thermoplastic with glass fill for increased durability and performance
Standard connector profile ensures compatibility with a variety of devices
Features a mating retention latch for added security during operation
Compliant with safety and environmental standards for peace of mind
Specially constructed for ease of installation and low maintenance requirements
Withstands challenging environmental conditions, ensuring long-term reliability
