Eaton C22 Moeller Series Turn to Release Emergency Stop Push Button, Built-In, 22.5 mm Cutout, 2 NC, IP13
- RS Stock No.:
- 127-612
- Mfr. Part No.:
- 182972 C22-PVT45P-MPI-K02-P1
- Brand:
- Eaton
Subtotal (1 unit)*
£84.61
(exc. VAT)
£101.53
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 03 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £84.61 |
*price indicative
- RS Stock No.:
- 127-612
- Mfr. Part No.:
- 182972 C22-PVT45P-MPI-K02-P1
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Mount Type | Built-In | |
| Product Type | Emergency Stop Push Button | |
| Cutout Diameter | 22.5mm | |
| Contact Configuration | 2 NC | |
| Push Button Actuation | Turn to Release | |
| Series | C22 Moeller | |
| Illuminated | No | |
| IP Rating | IP13 | |
| Colour | Red | |
| Terminal Type | Cable | |
| Contact DC Voltage | 24V | |
| Head Style | Palm-Tree Shaped | |
| Contact AC Voltage | 250V | |
| Contact Current | 4A | |
| Switch Configuration | 2 NO | |
| Depth | 297mm | |
| Hazardous Area Certification | No | |
| Standards/Approvals | CSA-C22.2 No. 94.2-07, UL File No.:E340491, VDE 0660, UL Listed, CSA-C22.2 No. 94-91, CSA-C22.2 No. 14-10, CE, CSA File No.:165628, CSA Class No.:321103, IEC/EN 60947-5-5, UL, UL 508, IEC/EN 60947-5-1, CSA | |
| Head Diameter | 45mm | |
| Length | 297mm | |
| Width | 45mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Mount Type Built-In | ||
Product Type Emergency Stop Push Button | ||
Cutout Diameter 22.5mm | ||
Contact Configuration 2 NC | ||
Push Button Actuation Turn to Release | ||
Series C22 Moeller | ||
Illuminated No | ||
IP Rating IP13 | ||
Colour Red | ||
Terminal Type Cable | ||
Contact DC Voltage 24V | ||
Head Style Palm-Tree Shaped | ||
Contact AC Voltage 250V | ||
Contact Current 4A | ||
Switch Configuration 2 NO | ||
Depth 297mm | ||
Hazardous Area Certification No | ||
Standards/Approvals CSA-C22.2 No. 94.2-07, UL File No.:E340491, VDE 0660, UL Listed, CSA-C22.2 No. 94-91, CSA-C22.2 No. 14-10, CE, CSA File No.:165628, CSA Class No.:321103, IEC/EN 60947-5-5, UL, UL 508, IEC/EN 60947-5-1, CSA | ||
Head Diameter 45mm | ||
Length 297mm | ||
Width 45mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
Eaton Emergency Stop Push Button, 22.5mm Cutout Diameter, 4P Pole and Throw Configuration - 182972 C22-PVT45P-MPI-K02-P1
This emergency stop push button is a Crucial industrial switch designed for safety and efficiency. It features a Durable palm-tree shape and operates with a turn-to-release mechanism for immediate action. The button has a cut-out diameter of 22.5mm and is built to withstand conditions with a rated operational current of 4A at 250V.
Features & Benefits
• Palm-tree shape ensures easy visibility and accessibility
• Turn-to-release mechanism provides quick operation in emergencies
• Non-illuminated design reduces distraction in critical environments
• Mechanical switch position indication enhances user confidence
• Features two normally closed contacts for reliable performance
• Robust construction allows for a lifespan of 50,000 operations
• Turn-to-release mechanism provides quick operation in emergencies
• Non-illuminated design reduces distraction in critical environments
• Mechanical switch position indication enhances user confidence
• Features two normally closed contacts for reliable performance
• Robust construction allows for a lifespan of 50,000 operations
Applications
• Used in machinery where immediate shutdown is essential
• Applicable in assembly lines for automated safety controls
• Suitable for industrial environments requiring emergency stop functions
• Effective in robotics for swift emergency intervention
• Ideal for controlling heavy equipment in manufacturing settings
• Applicable in assembly lines for automated safety controls
• Suitable for industrial environments requiring emergency stop functions
• Effective in robotics for swift emergency intervention
• Ideal for controlling heavy equipment in manufacturing settings
How does the push button ensure safe operation in high-risk environments?
This emergency stop device features two normally closed contacts, providing a reliable safety function by positively opening. This configuration reduces the risk of accidental activation while ensuring that any emergency can be promptly addressed.
What is the environmental tolerance of this push button?
The device operates effectively between -30°C to 70°C, making it suitable for various environmental conditions, from cold storage facilities to hot manufacturing environments. It also meets NEMA 4X and 13 ratings, highlighting its durability against dust and moisture.
How is the push button connected to the system?
It is equipped with a 0.2m cable and M12A plug, offering a straightforward connection to your existing systems. This facilitates quick installation and replacement, enhancing operational efficiency.
