TE Connectivity 1218408-2 15 Way Right Angle 2.77 mm Pitch Through Hole D-Sub Connector Female
- RS Stock No.:
- 504-049
- Distrelec Article No.:
- 304-48-596
- Mfr. Part No.:
- 1218408-2
- Brand:
- TE Connectivity
Subtotal (1 pack of 6 units)*
£171.09
(exc. VAT)
£205.31
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 31 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £171.09 | £28.515 |
*price indicative
- RS Stock No.:
- 504-049
- Distrelec Article No.:
- 304-48-596
- Mfr. Part No.:
- 1218408-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Number of Contacts | 15 | |
| Product Type | D-Sub Connector | |
| Current | 5A | |
| Orientation | Right Angle | |
| Mount Type | Through Hole | |
| Connector Gender | Female | |
| Connector Type D | D-Sub | |
| D-Sub Shell Size | 2 | |
| Housing Material | Steel | |
| Minimum Operating Temperature | -55°C | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 125°C | |
| Contact Gender | Female | |
| Standards/Approvals | 2016 Restricted Materials Above Threshold, China RoHS 2 Directive MIIT Order No 32, EU REACH Regulation (EC) No. 1907/2006 | |
| Contact Material | Brass, Beryllium Copper Alloy | |
| Series | 1218408-2 | |
| Contact Plating | Gold | |
| Contact Size | 20 | |
| Pitch | 2.77mm | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Number of Contacts 15 | ||
Product Type D-Sub Connector | ||
Current 5A | ||
Orientation Right Angle | ||
Mount Type Through Hole | ||
Connector Gender Female | ||
Connector Type D D-Sub | ||
D-Sub Shell Size 2 | ||
Housing Material Steel | ||
Minimum Operating Temperature -55°C | ||
Termination Type Solder | ||
Maximum Operating Temperature 125°C | ||
Contact Gender Female | ||
Standards/Approvals 2016 Restricted Materials Above Threshold, China RoHS 2 Directive MIIT Order No 32, EU REACH Regulation (EC) No. 1907/2006 | ||
Contact Material Brass, Beryllium Copper Alloy | ||
Series 1218408-2 | ||
Contact Plating Gold | ||
Contact Size 20 | ||
Pitch 2.77mm | ||
Non Compliant
- COO (Country of Origin):
- MX
The TE Connectivity receptacle connector in question is a meticulously designed solution for cable-to-board applications, featuring a robust board mount configuration that ensures reliability and durability in various electronic systems. With a compact 15-position setup and a shell size that enhances versatility, this product caters to demanding technical environments. It is engineered with high-performance materials, making it suitable for integration into sophisticated printed circuit boards. The connector’s design not only optimises space but also facilitates efficient signalling, thereby contributing to enhanced system performance. Its capability to operate within a wide temperature range further underscores its suitability for diverse applications. This product exemplifies the manufacturer’s commitment to quality and innovation, providing a trusted connection point for engineers and designers alike.
Engineered for seamless integration into a variety of electronic applications
Optimised for high reliability in signal transmission
Constructed with durable materials for extended service life
Supports a broad operating temperature range to suit various environments
Facilitates easy installation and maintenance with its board mount design
Provides a secure connection mechanism to enhance performance stability
